162
<< index < Outdoor
STEP 1002
STEP 1001
STEP 1007
STEP 1008
STEP 1009
AUDEX 1271
AUDEX 1272
AUDEX 1301
AUDEX 1302
IP55
230V - driver included in base - (TRIAC/IGBT) dimmable
1 x LED array 11,8W (LED incl.) - 250mA - 913lm - 2700K - CRI >97
CEILING -
350mA - required remote mounted driver see below
1 x LED array 6,25W (incl.) - 350mA - 2700K (633lm) or 3000K (673lm) - 3000K - CRI >95
FALSE ceiling = aperture : Ø 47 - depth : min. 50 mm - depth for driver in false ceiling : min. 70 mm
CONCRETE ceiling = aperture : Ø 47 - depth : min. 50 mm - depth for driver in concrete ceiling : min. 110 mm
CEILING -
IP55
DEVICE
DIM.
DRIVER
REQUIRED REMOTE MOUNTED DRIVER
1 x
2 x
1-2 x
1-2 x
1-2 x
2-6 x
LC (TRIAC/IGBT)
LC (TRIAC/IGBT)
DA (DALI)
DA (DALI)
D 6WT
D 18WT
D 15WP*
D 15WDA EU
D 15WDA US*
D 40WDP*
PU
+
(PUSH-DIM)
DA (DALI)
+
1-10 (1-10V)
PU (PUSH-DIM)
DA (DALI)
+
driver remote mounting: driver does not fit through cutout hole of fixture
*110V-230V
For warranty use only Trizo21® supplied LED drivers as mentioned.
For all specs and techs about drivers, see www.trizo21.com/drivers
FRAME alu
LC
LC
FRAME black
FRAME white
FRAME bronze
FRAME gold
DIM
COLOR LED
3000K
2700K
FRAME black
FRAME white
7Ty up OUT
Audy-In OUT
107
Ø 80
Choose beam:
N=narrow 12° or
M=medium 24° or
W=wide 40°
Ø60
Ø40
33
FALSE & CONCRETE ceiling
35
Choose beam:
M=medium 23°
or W=wide 40°
