CRI
90
L80B10
IP20
IP20
Dimmable 13.3W LED module, available with either 38° or 60°
half-diffusion angle and colour temperature of 2.700 K or 3.000 K.
220-240V ~50/60Hz
Material: aluminium
NEW TRIA®
LED MODULE
NEW TRIA®
95 mm 30° MOUNTING RING PIVOT ANGLE
All Watt measurements are based on the total wattage.
Output
W
Prod no.
Current
mA
Colour temperature
K
Luminous flux
lm
13,3
38°
1007409
350
2.700
1.130
1007410
3.000
1.200
60°
1007411
2.700
1.130
1007412
3.000
1.200
Options
Colour
Prod no.
Size
Round 30° pivot angle
1007444
Diameter: 110 mm, H: 26 mm
1007443
1007447
1007445
Round 30° recessed
1007452
Diameter: 103 mm, H: 55 mm
1007454
Square 30° pivot angle
1007446
L: 110 mm, W: 110 mm, H: 26 mm
1007448
Black
SLV NEW TRIA® | 17
