D
Die PALADIO Serie überzeugt durch her-
vorragende technische Werte. Sie ist mit
einem UGR-Wert von UGR < 19 entblen-
det und somit nach Arbeitsstättenrichtlinie
für Büroarbeitsplätze geeignet. Ein CRI > 90 ist für uns
selbstverständlich. Durch die eingesetzten sehr hoch-
wertigen LED und Netzteile können wir eine Lebensdauer
von L 80 | B10 | 72.000 h garantieren.
The PALADIO series convinces with outstanding technical
values. It is glare-free with a UGR value of UGR < 19 and is
therefore suitable for office workplaces in accordance with
the workplace directive. A CRI > 90 is a matter of course for
us. Thanks to the very high-quality LEDs and drivers used,
we can guarantee a service life of L80 | B10 | 72,000 h.
GLARE FREE
Die PALADIO TRACK bietet durch die integrierte 48V DALI-Stromschiene
ein hohes Maß an Flexibilität und Gestaltungsfreiraum in der Planung. Li-
neare, profilbündige Lichtelemente und Leuchten aus dem SATTLER
Portfolio lassen sich flexibel positionieren.
Thanks to the integrated 48V DALI track, the PALADIO TRACK offers a
high degree of flexibility and design freedom in planning. Linear, flush-
mounted light elements and luminaires from the SATTLER portfolio can
be positioned flexibly.
FLUSH MOUNT
UGR
< 19
Einfacher Wechsel der profilbündigen LENS-Lichtelemente
Easy replacement of the flush-mounted LENS light elements
PALADIO PRISM, blendfreies Arbeiten im Homeoffice
Glare free work in the home office
LIGHTING ELEMENTS
UGR <19 bei PALADIO PRISM*
Neu entwickelte Reflektortechnik
bis zu 2000 lm pro Meter
Effizienz 85%
UGR <19 for LENS and PRISM*
Newly developed reflector technology
up to 2000 lm per meter
Efficiency 85%
PRISM
UGR <19 bei PALADIO LENS
Hocheffizienter Linsenreflektor
Bis zu180 Lm/W
UGR <19 with PALADIO LENS
highly efficient lens reflector
Up to180 Lm/W
LENS
6
NO. 03|24
*PALADIO PRISM UGR -
komplett neu entwickelte UGR-Variante
Completely new developed UGR-variant
Mehrschichtige Mikroprismatik
multilayer microprismatic diffuser
3D Primärreflektoreinheit
3D primary reflector unit
LED
