ROSS GARDAM
ADAPT COLLECTION
^Used with Adapt Ottomans to create single backrests
Dimensions shown are indicative. For projects requiring specific dimensions, please get in contact.
UNIVERSAL TABLE
AT-450
W 450 D 450 H 650
PIVOTING TABLE
AT-350
W 350 D 350 H 480
ROUND OTTOMAN Ø500
AR-500
W 500 D 500 H 450
ROUND OTTOMAN Ø900
AR-900
W 900 D 900 H 410
JOINING LEG
AJL
W 278 D 115 H 255
UNIVERSAL/PIVOTING TABLE
ROUND OTTOMAN
OPTIONAL COMPONENTS
ARM/SINGLE BACKREST
ABA^
W 140 D 680 H 500
ACCESSORIES
AVAILABLE FINISHES
BLACK
POWDER COAT
LEG/DETAILS
CUSTOM
UPHOLSTERY
WHITE
LAMINATE
TOP
BLACK
LAMINATE
TOP
BLACK
POWDER COAT
LEG
WHITE
POWDER COAT
LEG/DETAILS
WHITE
POWDER COAT
LEG
LOUNGE
DESK / TOP & LEGS
BLACK
LAMINATE
TOP
BLACK
POWDER
COATED MDF /
STEEL
SIDE TABLE / TOP & LEG
UNIVERSAL & PIVOTING TABLE
BLACK
MIRROR
TOP
MATERIALS & POWER
LOUNGE
INTERNAL FRAME / The internal frame is constructed
from kiln-dried hardwood and plywood. The seat utilises
metal springs for support, creating a high level of comfort
and ensuring long-term endurance.
BACK & ARM / The back and arms are constructed from
plywood (lounge) or tubular steel and plywood (mid-back
lounge/high-back lounge/curved modules). Each back
and arm has a unique attachment bracket located under
the lounge making the changing of components as simple
as removing four bolts.
SEAT CUSHION AND UPHOLSTERY / Formed from shaped
polyurethane foam of different densities and polyethylene
terephthalate (PET) to create a supportive yet comfortable
seat. Upholstery and leathers are available in a range
of varying textures, durability and tactility properties.
Upholstery is selected at the time of ordering.
LEGS, NODES AND DETAILS / Made from tubular powder
coated steel, steel plate and plastic feet for leg inserts.
DESK
DESK TOP / Available in 18mm laminate with custom
materials available upon request (see Finishes above).
Each rear mounted desk requires two or three rear legs
to support the desk top and a central support bracket
which sits under the centre of the desk (on three seater
straight modules). The smaller rear legs of the lounge are
then removed as the entire lounge is supported by the
desk legs.
DESK LEGS AND BRACKET / Constructed from tubular
powder coated steel, powder coated steel plate and plastic
feet for leg inserts.
SIDE TABLE
TABLE TOP / Available in laminate and black mirror as a
standard with custom finishes including timber veneer
available upon request (see Finishes above). The table is
available in multiple configurations (see following pages)
and can be easily attached to any lounge via use of the
simple Adapt connectors which bolt into the underside of
the lounge - or with four legs for a movable table.
LEGS AND EDGE / Manufactured from tubular powder
coated steel, powder coated steel bar and plastic feet for
leg inserts.
UNIVERSAL/PIVOTING TABLE
TABLE TOP / Available in black powder coated MDF with
other materials available upon request.
TABLE BASE / Constructed from tubular powder coated
steel and powder coated sheet with a felt bottom
(Universal Table).
POWER INTEGRATION
Various integrated power solutions are available within the
Adapt collection. A power / USB module can be located
to the underside of any of the lounge or ottoman options.
This allows simple plug and play within the internal of any
of the lounge settings.
A built in power / USB module can be located directly into
the rear of any back. This offers an ideal location to power
up while using the rear desks (see following pages).
ENVIRONMENTAL
The Adapt lounge has been tested and is certifed
to conform with the Global Green Tag Scheme by
EcoSpecifier.
ECOSPECIFIER
GREEN TAG CERTIFIED
CUSTOM
LEATHER
BLACK
POWDER COAT
LEG/FRAME
WHITE
POWDER COAT
LEG/FRAME
TECHNICAL 06
