193
192
250
RAL 9005 JET BLACK 000
SLATE GREY 059
GREEN PATINA 008
WHITE 001
Other colours on request
REFERENCES
R e p l a c e with the colour code
MOUNTING
Wiring entry points in grey
Fixing kit included
Moon - ROGER PRADIER |
COLOUR CODES
R e p l a c e with the colour code
Ø 200 mm
MODELS
E27
E27 + SENSOR
CORNER PLATE
5
109 019
109 020
147 006
6
109 013
7
109 014
8
109 017
9
109 016
10
109 021
109 022
11
109 015
12
109 025
13
109 024
MODELS
GLOBES
E27
CORNER PLATES
1
SMOKED PMMA
109 001
147 004
OPAL PMMA
109 002
2
SMOKED PMMA
109 003
147 004
OPAL PMMA
109 004
3
SMOKED PMMA
109 007
OPAL PMMA
109 008
4
SMOKED PMMA
109 011
OPAL PMMA
109 012
SANDSTONE 054
LIMESTONE 053
RAL 6009 BRITISH GREEN 019
RAL 6009 FIR GREEN 067
12 13
10
9
8
7
5
4
11
3
6
1
2
| ROGER PRADIER - Moon
MODELS Ø200 mm
MODELS Ø300 mm
SOURCES
E27 - 60W max (models 1 to 4)
Ø 70 mm - H 150 mm max
E27 - 105W max (models 5 to 13) Ø 80 mm - H 200 mm max
Ø 300 mm
H 328 mm
W 300 mm
Ø 200 mm
H 229 mm
W 200 mm
H 410 . W 200 . D 317
1
H 320 . W 200 . D 317
2
H 321 . W 200
3
H 2 056 . W 646
4
Opal or smoked PMMA
Opal PMMA
models 5 to 13
models 1 to 4
H 410 . W 300
6
H 553 . W 300
7
H 598 . W 300
8
H 1 233 . W 300
9
H 1 273 . W 300
10
H 1 903 . W 300
11
H 2 440 . W 900 . D 300
12
H 2 391 . W 773
13
H 422 . W 300 . D 416
5
Moon
Aluminium
Opal or smoked Ø200 mm PMMA globe (models 1 to 4)
Opal Ø300 mm PMMA globe (models 5 to 13)
IP44 / IK08 / Class 1
Moon
SPARE GLOBES
SMOKED PMMA
165 015 607
OPAL PMMA
165 015 606
SPARE OPAL GLOBE
165 016 606
Ø 300 mm
