111
110
Other colours on request
Welded Aluminium sheet
metal assembly
Kent - ROGER PRADIER |
SOURCE
Prismatic pressed clear glass diffuser
MODELS
REFERENCES
R e p l a c e with the colour code
E27 (2450 lm)
Pathway
Spacing
H 2,20 m
2,50 m
3,50 m
H 339 mm
W 320 mm
D 430 mm
E27 - 105W max Ø 80 mm - H 140 mm max
MOUNTING
COLOUR CODES
R e p l a c e with the colour code
| ROGER PRADIER - Kent
MODELS
E27
CLEAR GLASS
127 006
FROSTED GLASS
127 007
CLEAR GLASS
127 008
FROSTED GLASS
127 009
CLEAR GLASS
127 010
FROSTED GLASS
127 011
CLEAR GLASS
127 012
FROSTED GLASS
127 013
CLEAR GLASS
127 014
FROSTED GLASS
127 015
5
4
3
1
2
RAL 7021 BLACK GREY 107
DARK GREY 006
SLATE GREY 059
RAL 7044 SILK GREY 105
RAL 9010 PURE WHITE 101
RAL 3013 TOMATO RED 110
RAL 5011 STEEL BLUE 065
BLUE 111
OLD RUSTIC 046
RAL 6025 FERN GREEN 109
RAL 6009 FIR GREEN 067
H 2 185 . W 320 . D 869
5
H 2 185 . W 320 . D 559
4
H 1 001 . W 320 . D 517
3
H 330 . W 320
1
H 339 . W 320 . D 430
2
E27 (2450 lm)
Real light output - 2055 lm
Glare-reducing ring
Wiring entry points in grey
Fixing kit included
Kent
Aluminium
Prismatic clear glass diffuser
IP44 / Class 1
SPARE DIFFUSER
CLEAR GLASS
165 111 609
FROSTED GLASS
165 111 610
PRM Average Illuminance 20 lux p.300
Model 4
250
1
2
3
4
5
