REFERENCES
Tetra - ROGER PRADIER |
| ROGER PRADIER - Tetra
MOUNTING
Wiring entry points in grey
Fixing kit included
Anchor bolts on request (model 5) p.302
MODELS
SOURCES
LED 12W - 2700K warm white
E27 - 70W max - 230V Ø 66 mm - H 175 mm max (with bulb cover)
Ø 80 mm - H 180 mm max (without bulb cover)
E27 Class 3 - 8W max - 12-24V Ø 66 mm - H 175 mm max (with bulb cover)
Ø 80 mm - H 180 mm max (without bulb cover)
LED 12W
Pathway
Spacing
H 1,10 m
2,00 m
12,00 m
1
2
5
to
COLOUR CODES
R e p l a c e with the colour code
RAL 9005 JET BLACK 000
DARK GREY 006
METAL GREY 023
WHITE 001
RAL 9010 PURE WHITE 101
RAL 5011 STEEL BLUE 065
RAL 3013 TOMATO RED 110
RAL 3020 TRAFFIC RED 056
OLD RUSTIC 046
RAL 6025 FERN GREEN 109
MODELS
E27
E27
Class 3
LED SYMMETRIC
12W 2700K warm white
LED ASYMMETRIC
12W 2700K warm white
1
162 001
162 036
162 306
2
162 007
162 037
162 211
162 111
3
162 012
162 038
162 216
162 116
4
162 017
162 039
162 221
162 121
5
162 022
162 326
MODEL
E27
E27
Class 3
LED SYMMETRIC
12W 2700K warm white
LED ASYMMETRIC
12W 2700K warm white
1
162 002
MODEL
E27
E27
Class 3
LED SYMMETRIC
12W 2700K warm white
LED ASYMMETRIC
12W 2700K warm white
4
162 031 ( )
162 233 ( )
162 133 ( )
MODEL
E27
E27
Class 3
LED SYMMETRIC
12W 2700K warm white
LED ASYMMETRIC
12W 2700K warm white
4
162 035
162 235
162 135
With sensor
With sockets
With reinforced
Green’Up 16A
socket
see p.296
SOCKET CODES
type F
type J
Extruded Aluminium section
Directionnal LED
H 300 mm
W 170 mm
D 116 mm
LED version - Ulor<1%
E27 version
symmetric or asymmetric
with stainless steel bulb cover
H 2 100 . W 170 . D 100
5
Models 1 and 5
LED 12W SYM
Real light output - 680 lm
CRI > 80
Models 2 to 4
LED 12W SYM
Real light output - 797 lm
CRI > 80
Models 2 to 4
LED 12W ASYM
Real light output - 879 lm
CRI > 80
Tetra
Aluminium
Clear polycarbonate diffuser
Stainless steel bulb cover (E27 version)
IP65 / IK10 / Class 1 / Class 3
LED (Sécurlite technology) - Symmetric or Asymmetric version (except models 1 and 5)
- see p.300
Tetra
SPARE DIFFUSER
165 066 601
SPARE BULB COVER (E27)
165 075 018
Clear polycarbonate diffuser
Shutter
to restrict light output from the back
2 angles
SYM
LED
SYM
LED
ASYM
LED
H 500 . W 170 . D 100
2
H 800 . W 170 . D 100
3
H 1 100 . W 170 . D 100
4
H 300 . W 170 . D 116
1
SYM
LED
SYM
LED
ASYM
LED
SYM
LED
SYM
LED
SYM
LED
ASYM
LED
ASYM
LED
ASYM
LED
PRM Average Illuminance 20 lux p.300
Model 4 ASYM
