20
4000 K
CRI >90
3500 K
CRI >90
3000 K
CRI >90
CRI >95
2700 K
CRI >90
EN
Traceline offers excellent performances thanks to the integration of latest
generation light sources. The range includes Mid Power LEDs, with performance up to
170lm/w, High output and Mid output versions, options with high CRI> 95 and dynamic-
white versions: Warm Dimming 1800-2700K and Tunable White 2200-6500K.
IT
Traceline offre performance eccellenti grazie all’integrazione di sorgenti luminose
di ultima generazione. La gamma proposta include LED Mid Power con performance
fino a 170lm/w, versioni High output e Mid output, opzioni con CRI elevato >95 e versioni
con bianco dinamico: Warm Dimming 1800-2700K e Tunable White 2200-6500K.
MID POWER LED
EN Different solutions with Mid Power LED:
IT Differenti soluzioni con LED Mid Power:
- 224 LED/m, 150 lm/w
(Opal, Micro Prismatic, Dark Grid, PMMA Lens 11°/48°)
- 112 LED/m, 170 lm/W
(Dark Performance)
- Warm Dimming, Tunable White
(Opal)
- LED tape IP20 CRI>95 and IP65 CRI>90.
(Fade)
EN The Dark Performance optical version is available with HC LED (CRI>
95) - 3000K (on request for other CCTs).
Thanks to an excellent color rendering and TM30 values of Rg = 90 and
Rf = 100 it allows the use of Traceline also in commercial and residential
applications where a very high CRI value is required.
IT La versione ottica Dark Performance è disponibile con LED HC
(CRI>95) - 3000K (a richiesta per altri CCT). Con un eccellente resa
cromatica e valori TM30 di Rg=90 e Rf=100 permette l’utilizzo di
Traceline anche in applicazioni commerciali e residenziali dove viene
richiesto un valore di CRI molto elevato.
EN Wide range of LED temperatures:
- from 4000 K to 2700K with CRI>90 and 3000K options with CRI>95.
- Step Mc Adam < 3 and L80 B50: 50.000h
- Version with Opal diffuser (High output and Mid output) to meet different lighting needs.
IT Ampia gamma di temperature LED:
- da 4000 K a 2700K con CRI>90 e opzioni a 3000K con CRI>95.
- Step Mc Adam < 3 e L80 B50: 50.000h
- Versione con diffusore Opal (High output e Mid output) per rispondere ad esigenze di
illuminamento differenti.
LED
