Re Low Led Fixed
330
Re Low LED Comfort | Round | LED RETROFIT
Risk 1 0.22 Kg IP23
850°
CB
COB LED
LED RETROFIT
119
ø82
ø35
ø82
ø35
ø87
Re Low LED | Round | LED RETROFIT
Risk 1 0.17 Kg IP43
850°
CB
COB LED
LED RETROFIT
94
ø68
ø68
ø68
60
ø66
Code example:
X . 7E31
B . HW 12
Accessories: p.334
Drivers: p.334
Finishes: p.324
Photometric data:
www.reggiani.net
ø60
Code example:
X . 3E31
B . HW 01
Accessories: p.334
Drivers: p.334
Finishes: p.324
Photometric data:
www.reggiani.net
5 W
COB LED
Lumen delivered up to 675 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
7E31
B
14° Narrow
HW
2700
>90
670
<3
12
E
29° Medium
HQ
3000
>90
715
<3
28
H 37° Wide
WW
3000
>80
820
<3
31
M 64° Very wide
NN
4000
>80
855
<3
K -
Without optics
LED nominal lumen
9 W
COB LED
Lumen delivered up to 1170 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
7E32
B
16° Narrow
HW
2700
>90
1160
<3
12
E
30° Medium
HQ
3000
>90
1210
<3
28
H 41° Wide
WW
3000
>80
1435
<3
31
M 70° Very wide
NN
4000
>80
1505
<3
K -
Without optics
LED nominal lumen
17 W
LED RETROFIT (Lamp not included)
Transformer
Version
LED LAMP
Watt
Finishes
0
Not included
03790.00
GU5.3
Max power: 17W
01
05
10
28
21
Code example:
0 . 03790.00 01
Transformer: p.335
5 W
COB LED
Lumen delivered up to 675 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
3E31
B
14° Narrow
HW
2700
>90
670
<3
01
E
29° Medium
HQ
3000
>90
715
<3
05
H 37° Wide
WW
3000
>80
820
<3
12
M 64° Very wide
NN
4000
>80
855
<3
28
K -
Without optics
LED nominal lumen
31
9 W
COB LED
Lumen delivered up to 1170 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
3E32
B
16° Narrow
HW
2700
>90
1160
<3
01
E
30° Medium
HQ
3000
>90
1210
<3
05
H 41° Wide
WW
3000
>80
1435
<3
12
M 70° Very wide
NN
4000
>80
1505
<3
28
K -
Without optics
LED nominal lumen
31
17 W
LED RETROFIT (Lamp not included)
Transformer
Version
LED LAMP
Watt
Finishes
0
Not included
03758.00
GU5.3
Max power: 17W
10
28
21
Code example:
0 . 03758.00 01
Transformer: p.335
