Re Low LED
326
Sizes and tech.
specifications/
Misure e info tecniche
FIXED
68 mm
82 mm
102 mm
Re Low LED
Fixed
Comfort Round
Visible trim Ø82 mm
p.330
IP65*
Visible trim Ø82 mm
p.331
Re Low LED
Fixed
Round
Visible trim Ø68 mm
p.330
Re Low LED
Fixed
IP65 Round
Visible trim Ø102 mm
p.331
Max recess depth/
Ingombro interno massimo
94
119
107
Ø60
Ø60
Ø66*
Ø86
Beam width/
Apertura cono di luce
5 W 14°, 29°, 37°, 64°
9 W 16°, 30, 41°, 70°
5 W 14°, 29°, 37°, 64°
9 W 16°, 30, 41°, 70°
5 W 14°, 29°, 37°, 64°
9 W 16°, 30, 41°, 70°
Light source/
Sorgente luminosa
COB LED
5 W, 9 W
670 lm-1505 lm
L80 B10=50,000h
2700 K, 3000 K, 4000 K
SDCM <3
CRI >80, CRI >90
LED RETROFIT (Not included)
Max 17W
COB LED
5 W, 9 W
670 lm-1505 lm
L80 B10=50,000h
2700 K, 3000 K, 4000 K
SDCM <3
CRI >80, CRI >90
LED RETROFIT (Not included)
Max 17W
COB LED
5 W, 9 W
670 lm-1505 lm
L80 B10=50,000h
2700 K, 3000 K, 4000 K
SDCM <3
CRI >80, CRI >90
