Bisio
314
Ø 100 mm | Accessories
Ø 100 mm
Risk 1 0.54 Kg IP20
850°
CB
155
ø117
ø117
ø100
-35°+90°
358°
Code example:
X . B682
B . HW 10
Accessories: p.314
Drivers: p.317
Finishes: p.308
Photometric data:
www.reggiani.net
9 W
COB LED
Lumen delivered up to 1170 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
B682
B
16° Narrow
HW
2700
>90
1160
< 3
10
E
30° Medium
HQ
3000
>90
1210
< 3
28
H 41° Wide
WW
3000
>80
1435
< 3
M 70° Very wide
NN
4000
>80
1505
< 3
K -
Without optics
LED nominal lumen
12 W
COB LED
Lumen delivered up to 1560 lm / Lumen maintenance: L80 B10=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Finishes
X
Not included
B683
B
16° Narrow
HW
2700
>90
1560
< 3
10
E
30° Medium
HQ
3000
>90
1615
< 3
28
H 41° Wide
WW
3000
>80
1935
< 3
M 70° Very wide
NN
4000
>80
2030
< 3
K -
Without optics
LED nominal lumen
Accessories/
Accessori
Description
Code
Finishes
Trimless bezel Ø 100 mm/
Supporto faro Ø 100 mm
0.10000.00
10
Description
Code
Emergency pack/
Gruppo di emergenza
0.35081.0000
Emergency pack including Ni/Cd battery with 1h back-up/
Gruppo di emergenza con batterie Ni/Cd autonomia 1h
Description
Code
Hole cutter Ø 100 mm/
Frese per fori Ø 100 mm
0.11100.0000
Description
Code
Emergency pack/
Gruppo di emergenza
0.35081.UK00
Emergency pack including Ni/Cd battery with 3h back-up/
Gruppo di emergenza con batterie Ni/Cd autonomia 3h
Description
Code
Hole cutter handle/
Maniglia per frese
0.10099.0000
Description
Code
Extension lead/
Prolunga
0.35100.0000
�������������������������������������������������������������������
Cavo bipolare da 3m completo di spina e presa ad innesto rapido
Interchangeable IOS optics/
Ottiche intercambiabili IOS
Description
Code
LL1 - Narrow beam/
LL1 - Fascio stretto
0.35011.0000
(16°-9W, 12W)
Description
Code
LL1 - Wide beam/
LL1 - Fascio largo
0.35013.0000
(41°-9W, 12W)
Description
Code
LL1 - Medium beam/
LL1 - Fascio medio
0.35012.0000
(30°-9W, 12W)
Description
Code
LL1 - Very wide beam/
LL1 - Fascio molto largo
0.35014.0000
(70°-9W, 12W)
