Cells
37
Opal diffuser/Diffusore Opale
Risk 0 2,10 Kg IK10 IP66
850°
91.5
201
201
Code example:
0 . CG03 0 . WW 48
Accessories: p.38
Notes:
- In chart nominal Lumen/ In
tabella Lumen nominali.
- Version 13W: for environments
up to 50 °C/ Versione 13 W: per
ambienti fino a 50 °C.
*3 hours emergency - When
operating in emergency mode,
luminous flux is 30% of the
lumens emitted under normal
operating conditions/
*Versione emergenza 3 ore - Il
prodotto in funzionamento di
emergenza emette il 30% del
flusso emesso in condizioni
standard.
Photometric data:
www.reggiani.net
13 W
LED ARRAY
Lumen delivered up to 1015 lm / Lumen maintenance: L70 B50=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Body
Plates
Euro
0
On/Off
CG03
0
81° Very wide
WW
3000
>80
2096
<3
48
White plate only
0.
322,00
D
DALI
On request:
4000K (CRI >80)
Tunable white: (2700K-6500K)
08
D.
396,00
On request
28
H
Bluetooth
98
13 W
Emergency* LED ARRAY
Lumen delivered up to 1015 lm / Lumen maintenance: L70 B50=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Body
Plates
Euro
0
On/Off
NG03
0
81° Very wide
WW
3000
>80
2096
<3
48
White plate only
0.
322,00
D
DALI
4000K (CRI >80)
08
D.
396,00
28
98
18 W
LED ARRAY
Lumen delivered up to 1240 lm / Lumen maintenance: L70 B50=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Body
Plates
Euro
0
On/Off
CG04
0
81° Very wide
WW
3000
>80
2560
<3
48
White plate only
0.
322,00
D
DALI
On request:
4000K (CRI >80)
Tunable white: (2700K-6500K)
08
D.
396,00
On request
28
H
Bluetooth
98
18 W
Emergency* LED ARRAY
Lumen delivered up to 1240 lm / Lumen maintenance: L70 B50=50,000h
Driver
Version
Optics
LED
K
CRI
lm
SDCM
Body
Plates
Euro
0
On/Off
NG04
0
81° Very wide
WW
3000
>80
2560
<3
48
White plate only
0.
322,00
D
DALI
4000K (CRI >80)
08
D.
396,00
28
98
Finishes / Finiture
Body
48
White/Bianco
08
Graphite/Grafite
28
Grey/Grigio
98
Raw aluminium/Alluminio grezzo
