FEATURES
Power (W)
12 - 24 - 30
Installation
Suspension, ceiling, wall, track or Jbox
Luminaire housing
Aluminium
Protective screen
Polycarbonate
Finishing
Natural anodised, black anodised
Line voltage
120V 60Hz
Dimming
0 -10V dim
2BE
Design: Enrico Corelli
Luminaire with LED lighting system.
Wall-mounted, ceiling, high-bay installation.
Polycarbonate louver protection.
65mm
2,55 inch
700 - 1590 mm
27,56" - 62,60"
2BE
TB103 12W
TB107 12W
TB105 30W
TB109 30W
For dry location
TB104 24W
TB108 24W
W/ft
3000 K CRI 80
4000 K CRI 80
5.5
650 lumens/ft
685 lumens/ft
Ordering info
Model
Color
Lenght
Finish
-----
----
--
TB103 12W120V
TB104 24W120V
TB105 30W120V
8030
8040
27,56”
51,18”
62.60”
02 black
18 grey
Other on request
Ordering example :TB103 8030 02
Ordering info
Model
Adapter
Color
Lenght
Finish
-----
-
----
--
TB107 12W120V
TB108 24W120V
TB109 30W120V
X Global(*) XTS compatible
8030
8040
27,56”
51,18”
62.60”
02 black
18 grey
Other on request
Ordering example :TB103 X 8030 .02
Accessories
TBA01
Bracket for ceiling/wall mounting (white-black-gray)
TBA12
n° 2 steel supporting cables with quick fix system
Length of cables 98,42” (white-black-gray)
TBA13
n° 2 steel supporting cables with quick track fix system
Length of cables 98,42” (white-black-gray)
TBA14
n° 1 steel supporting cables with quick track fix system
n° 1 steel supporting cables with quick ceiling fix system
97 mm
3,81 inch
65 mm
2,55 inch
50 mm
1,96 inch
