puk.it | 575
Technical data
Wattage
42 WATT
IP Rating
IP66
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
1 x COB CREE “CXB 2540” LED
Screws
Stainless steel
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. power cable included
Gross weight
4,50 Kg
Technical features
Surface mounted luminaire for outdoor ceiling
installation. Phospho-chromatised and polyester
powder coated die-cast copper-free aluminium base
and head, tempered safety glass, moulded silicone
gaskets, with screws in stainless steel. Built-in LED
driver, with 1 COB CREE “CXB 2540” LED. IP66 rating.
701104
QUBO MAXI COB
DOWNLIGHT
5
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
cob led
14°
4.950
117.85
cob led
35°
4.752
113.14
cob led
55°
4.560
108.57
4000°K neutral-white
cob led
14°
5.265
125.36
cob led
35°
5.000
119.05
cob led
55°
4.770
113.57
2700°K CCT available on request
AC074
HONEYCOMB LOUVER
Finish color options:
Textured Grey
RAL 9006
Anthracite Grey
RAL 7016
Matt Black
(on request)
Technical data
Wattage
20 WATT
IP Rating
IP66
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
3 x CREE “XHP35” LED
Screws
Stainless steel
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. power cable included
Gross weight
3,10 Kg
170 mm
180 mm
170 mm
DALI
1 - 10V
Available on request
