Technical data
IP Rating
IP67
IK Rating
IK08
Material
high corrosion resistance
extruded copper-free
aluminum
Coating
anodizing treatment +
protective powder coating
Screws
Stainless steel
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gasket
Silicone rubber
Glass
Tempered
Cable gland
PG9 cable gland
Power cable
1 mt. neoprene power cable
included, in & out cable for
loop-in loop-out connection
available on request
403304
LINEAFACADE 300 DIFFUSED
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700°K warm-white
high-power led
DIFFUSED
300
37.50
3000°K warm-white
high-power led
DIFFUSED
310
38.75
4000°K neutral-white
high-power led
DIFFUSED
330
41.25
403308
LINEAFACADE 600 DIFFUSED
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700°K warm-white
high-power led
DIFFUSED
500
41.66
3000°K warm-white
high-power led
DIFFUSED
520
43.33
4000°K neutral-white
high-power led
DIFFUSED
550
45.83
Technical data
Class
Wattage
8 WATT
Light Source Nr. 12 SAMSUNG 3030 LED
Gross weight 1,70 Kg
Technical data
Class
Wattage
12 WATT
Light Source Nr. 24 SAMSUNG 3030 LED
Gross weight 3,00 Kg
Finish color options:
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
Finish color options:
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
290 mm
90 mm
83 mm
56 mm
580 mm
90 mm
83 mm
56 mm
