puk.it | 333
AC114
STANDARD GLARE SHIELD
Glare shield accessory made in hard anodized black aluminum, providing good
balance in between glare control and light output.
AC115
SUPER COMFORT GLARE SHIELD
Glare shield accessory made in hard anodized black aluminum, for applications
requiring very reduced glaring; minimal light loss on the light surface but overall
lumen output typically reduced by 50%.
AC064
HYONECOMB LOUVER
700 mA – LED POWER 10W
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
2700°K warm-white
high-power led
4°
897
89.70
high-power led
10°
762
76.20
high-power led
28°
836
83.60
high-power led
55°
711
71.06
3000°K warm-white
high-power led
4°
907
90.69
high-power led
10°
872
87.20
high-power led
28°
846
84.60
high-power led
55°
719
71.91
4000°K neutral-white
high-power led
4°
930
93.00
high-power led
10°
890
89.00
high-power led
28°
863
86.30
high-power led
55°
734
73.36
500 mA – LED POWER 8W
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
2700°K warm-white
high-power led
4°
670
83.75
high-power led
10°
642
80.25
high-power led
28°
622
77.75
high-power led
55°
529
66.09
3000°K warm-white
high-power led
4°
690
86.25
high-power led
10°
662
82.75
high-power led
28°
642
80.25
high-power led
55°
546
68.21
4000°K neutral-white
high-power led
4°
703
87.88
high-power led
10°
676
84.50
high-power led
28°
656
82.00
high-power led
55°
558
69.70
AC064
HONEYCOMB
LOUVER
