288 | puk.it
201211
LINEAGROUND 900 TRIMLESS HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
1.950
65.00
high-power led
30°
1.905
63.50
high-power led
60°
1.860
62.00
high-power led
10x60°
ELLIPTICAL
1.905
63.50
Technical data
Class
Wattage
30 WATT
Light Source NR. 36 TUNABLE-WHITE
3535 LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 7,00 Kg
201215
LINEAGROUND 1200 TRIMLESS HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
2.600
65.00
high-power led
30°
2.540
63.50
high-power led
60°
2.480
62.00
high-power led
10x60°
ELLIPTICAL
2.540
63.50
Technical data
Class
Wattage
40 WATT
Light Source Nr. 48 TUNABLE-WHITE 3535
LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 9,50 Kg
Finish color options:
Glass
Finish color options:
Glass
880 mm
56 mm
81 mm
LUMINAIRE
RECESS HOUSING
62 mm
109 mm
884 mm
145 mm
1180 mm
56 mm
81 mm
LUMINAIRE
RECESS HOUSING
62 mm
109 mm
1184 mm
145 mm
