puk.it | 201
Technical data
Wattage
14 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
3 x CREE “XML”
COLOR RGBW LED
Screws
Stainless steel
DMX
DMX interface integrated
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. neoprene power cable
included
DMX cable
DMX IN cable included
Gross weight
2,40 Kg
Ground-recessed luminaire in round shape for
outdoor installation, phospho-chromatised
and polyester powder coated die-cast
copper-free aluminium body and stainless
steel AISI 304 frame, tempered safety glass,
moulded silicone gasket. Built-in LED driver,
DMX driver integrated; with 3 x CREE “XML”
RGBW LED. IP67 rating.
HYDROFLOOR MEDIUM
DMX RGBW
201068RGBW
Technical data
Wattage
19 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
Nr. 1 CREE CXB 2530 COB LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Static weight
resistance
Max 5000 Kg
Gasket
Silicone rubber
Glass
Tempered
Cable gland
Double M20
Power cable
1 mt. neoprene power cable
included
Gross weight
4,00 Kg
Included
Polypropilene recessing box
included
Stainless Steel
Finish color options:
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
RGBW
high-power led
12°
480
34.28
high-power led
25°
468
33.43
high-power led
35°
457
32.65
DMX ACCESSORIES
CONTROLLERS, SPLITTERS, ETC…
To be defined together with puk technical department, according to project specifications and after providing installation details.
Ø 190 mm
HOLE FOR RECESSING Ø 179 mm
210 mm
2 mm
Technical features
5
+/- 15°
DMX
5000
DALI
Available on request
