puk.it | 133
OTHER VIEW
Technical data
Wattage
Max 7 WATT
IP Rating
IP66
IK Rating
IK09
Material
Stainless steel AISI 316L
Light source
1 x CREE XHP35 LED
Screws
Stainless steel
Remote driver
Constant current max
500mA
Gasket
Silicone rubber
Glass
Tempered
Power cable
1,5 mt. power cable
included
Gross weight
1,10 Kg
remote driver selection
brand
manufacturer code
type
watt
IP rate
numbers of fixtures
ALVIT Italy
AL1435S-IP
Constant current 350mA
14W
IP67
min 1 – max 2
ALVIT Italy
AL1450S-IP
Constant current 500mA
14W
IP67
1
TCI Italy
152014/350
Constant current 350mA
17W
IP68
min 1 – max 3
TCI Italy
152014/500
Constant current 500mA
24W
IP68
min 1 – max 3
500 mA – LED POWER 7W
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
high-power led
4°
690
98.57
high-power led
10°
662
94.57
high-power led
28°
642
91.71
high-power led
55°
546
77.95
4000°K neutral-white
high-power led
4°
703
100.43
high-power led
10°
676
96.57
high-power led
28°
656
93.71
high-power led
55°
558
79.65
AC044
SPIKE
AC095
HONEYCOMB LOUVER
AC038
TREE STRAP
OPTIONAL
AC127
ANTI-GLARE SNOOT
