L I N E A R L I G H T I N G | F L E X S T R I P S
L......Z
per metre. For custom length, add Z to the end of the
order code and state the required length. Please note
reel length and cutting intervals. See main catalogue for
more information on special lengths and customising.
*With correct installation and suitable thermal management.
Due to production tolerances, photometric data may vary from production batch to production
batch within the EU directive.
Beam angle 120°
See main catalogue for accessories
Order power supply separately
L6V4800
RGB
490 lm/m
49 lm/W
G
red
120 lm/m
green
300 lm/m
blue
70 lm/m
IP rating: IP20
Power source: 48 VDC
Electrical connection: 2x cable to open wires; 4-pin; 30 cm
Max. power consumption per reel: 200 W
Power consumption per m: 10 W/m
Max. quantity per power input: 20 m
Average lifetime*: 50.000 h at L80/B10
Operating temperature range: -10°C to 45°C
Dimensions: 20000 x 14 x 2 mm (l x w x h)
Min. bending radius: 20 mm
Cutting intervals: 167 mm
No. LEDs per m: 78
Product weight: 0,53 kg
Warranty
5
YEARS
P R O L E D F l e x S t r i p
Xtend RGB
52 | new
proled.com
