92 | URBAN
Street light series. Fixtures consist of:
Construction
- Die-cast aluminium housing and cap, chemical pre-treated and painted polyester powder coating
ISO 9227
- Technopolymer component holder bracket reinforced with fiberglass
- Aluminium heat sink
- High-transparency polycarbonate lenses grant an optimized light transmission
- High resiliency anti-ageing silicone gasket with high elastic return capacity
- Extra clear, tempered, flat glass diffuser
- Fully integrated stainless steel aluminium spring clips
- Stainless steel external screws
- Painted die-cast aluminium pole clamp
Electrical
- Integral surge protection device (SPD) against mains overvoltages up to 10 kV
- The “SECURE LIGHT DISTRIBUTION” system guarantees uniform light distribution even in the
remote case of LED failures
- Provided complete with 1 m cable H07RN-F 2 x 1.5 mm2 and IP66 plug-socket, produced in
polyamide with silver-plated brass contacts, for cables Ø 9 - Ø14 mm, that allows connection to
the mains without opening the luminaire.
Installation
- KYRO+1 versions are suitable for installation on Ø 42 - Ø 60/62 mm poles, KYRO+1-D76 versions
on Ø 76 mm poles, and KYRO+2 versions on Ø 60/62 - Ø 76 mm poles
- Gear tray removable without tools
- Switch splitter automatically disconnects the power supply when the cable cover is opened
- Waterproof cable gland M25x1.5 for cables Ø 9- Ø 14 mm
- Suitable for pole-tops Ø 60 / 76 mm.
Variants
- Versions with automatic power reduction available (RPA)
- CLO (Constant light output) option available. Consult factory
Listings
- CE
- EAC
- RCM
- Compliant with the UNI 10819 standards on light pollution
- Complies with CAM for public lighting fixtures
- Made in Italy
Warranty
- 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
- Registered trademark ®
KYRO+
design Silvia Paola Pennacchio
