PERFORMANCE iN LIGHTING | powered by GEWISS
SMART [3]
850° C
≥ +50° C
03
110
90
76
1600
110
90
76
1200
110
90
76
800
SMART [3]
1600
SMART [3]
1200
SMART [3]
800
Albinoleffe stadium - Zanica - Italy
Watertight fixture IP66/69 for industrial applications, ideal for production areas,
warehouses, and logistics areas
¬ Designed to replace fluorescent devices and lowbays up to 6,500 lm
¬ IK08 body in RAL7035 colored self-exhausting polycarbonate
¬ Available in 3 sizes: 800 mm, 1200 mm and 1600 mm
¬ Available in 3000 K, 4000 K and 5700 K, with CRI ≥80
¬ Available with powers ranging from 18W to 58W and flux ranging from 1,700lm to
6,500lm
¬ Mid-power LED with wire bonding
¬ Available with integrated On/Off or DALI driver
¬ The through wiring version has pre-wired mechanical and electrical connections
as accessories (to be ordered separately), allowing up to 25 fixtures installed in a
continuous row
¬ Available in 2 different optical solutions: trasparent or opal diffuser in UV-stabilized,
self-extinguishing polycarbonate
¬ The device can be hung or wall-mounted through bracket accessory with a tilt of
30° or 45° on the vertical axis
¬ External emergency kit with 3h autonomy compatible with through wiring versions
available (to be ordered separately)
J Grey RAL 7035 / Grey RAL7035 /
Scan the QR-code for
the latest information
288
