Wall-mounted LED luminaire, comprising:
Construction
- Die-cast aluminium housing, polyester powder coat finish ISO 9227/12944 -
ISO 9223 (C5)
- High-efficiency metallized technopolymer reflector with protective surface
treatment
- Anti-ageing custom moulded silicone sealing gasket(s)
- Extra clear, toughened, flat glass diffuser
Electrical
- Static ON/OFF or dimmable DALI options available
- EM/3P version is designed for multipurpose 3 hours sustained emergency
lighting
- Li-Fe Po4 3,2 V 3.0 Ah batteries, 24 hours recharge time
Installation
- Field settable integral tri-level lumen/wattage packages proprietary DIP
switch driver
- Through-wiring designed
- EXTREME options are suitable for extreme operating temp. conditions , -40°C
Variants
- Twilight models (C versions) complete with dusk sensor available. Consult
factory
Listings
- CE / UKCA
- RCM
Warranty
- 5-year limited warranty. Complete warranty terms located at
www.performanceinlighting.com
SHIELD
