Linear in-ground series. Fixtures consist of:
Construction
- Extruded anodised aluminium housing
- IP-67-rated double resin coating - transparent in the lower part to protect
the LED from mechanical stresses and to guarantee maximum luminous
efficiency - satin finish in the visible part, even in joints proximity, to ensure a
homogeneous light distribution over the entire emitting area
Electrical
- External power supply 48V has to be ordered separately
- Electronics are designed to maintain the constant brightness of all LED
modules in the light configuration without voltage drops
Installation
- Through-wiring designed
- Technopolymer external box for electrical connection suitable for Ø 6 - 9
mm rubber cables. This is connected to the appliance with a 25 cm cable. It
allows the appliance to be installed and connected without having to open it
- Two-part fitting, consisting of LED luminaire and stainless steel recess box
with anti-deformation cover (included). Tool-free installation of the luminaire
in the recess box
- Recessed box to be ordered separately
- For outdoor applications, provide drainage gravel for at least 300 mm
additional to the appliance or a suitable drainage system
- Suitable for low-speed transit of vehicles with inflated tyres
Variants
- RGBW and Tunable White versions to be powered with SELV drivers 48V
DC, available as accessories to be ordered separately. Colour management
through DMX interface
- DMX signal generator for RGBW and Tunable White versions to be ordered
separately
- Continuous mounted options and many other configurations are available at
www.light-performer.com
Listings
- CE / UKCA
- EAC
- RCM
- Compliant to EN 60598-2-13 A1 / A2 / A3 / A4 / A5 installation areas
- Made in Italy
Warranty
- 5-year limited warranty. Complete warranty terms located at
www.performanceinlighting.com
GROOVE
design artec3 Studio
