Design-coordinated area/site lighting (SPILLO) and bollard (SPILLO MINI) series. Fixtures consist of:
Construction
- ISO 9227 painted die-cast aluminium housing
- Anti-ageing silicone gasket
- Stainless steel external screws
Electrical
- Supplied complete with 220/240 V 50/60 Hz power supply unit.
- Analogue dimmable HF ballast, 1-10 V
- The “SECURE LIGHT DISTRIBUTION” system guarantees uniform light distribution even in the
remote case of LED failures
- Each LED is coupled with an electronic safety device (NUD) that can by-pass it in case of failure
- It is possible to replace the LED boards to keep the luminaire technologically updated through
the years (consult factory).
Installation
- Suitable for pole-tops Ø 60 / 76 mm or on SPILLO pole Ø 90 mm
- Waterproof cable gland M25x1.5 for cables Ø 9- Ø 14 mm
- Supplied with 1m pre-wired HORNF-5 cable
- External electrical connection with sealed plug-socket QUICK, complete with cable
Listings
- CE
- EAC
- RCM
- ENEC
- Complies with CAM for public lighting fixtures
- Made in Italy
Warranty
- 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
SPILLO
design Alessandro Pedretti
