AVATA R P O P
REF. 30021/125
AVATA R P O P
REF. 30021/300
AVATA R P O P
REF. 30021/200
Long. 125 cm
Long. 200 cm
AVATA R P O P
REF. KIT 30021/1
AVATA R P O P
REF. KIT 30021/2-3-4
41
6
3.5
40
11
3.5
SUSPENSION / COLGANTE
IP20
MATERIAL
Aluminium and polycarbonate / Aluminio y policarbonato
FINISHES ⁄ ACABADOS
Driver box and profiles ⁄ Caja driver y perfiles:
Black ⁄ Negro
Cable:
Black ⁄ Negro
Diffuser / Difusor:
Optic white ⁄ Blanco óptico
INSTALLATION / INSTALACIÓN
REF. 30021/125:
PCB-LED 21,5W 700mA CRI > 90
- 2700K 1541lm
- 3000K 1605lm
- 4000K 1680lm
REF. 30021/200:
PCB-LED 34,4W 700mA CRI > 90
- 2700K 2466lm
- 3000K 2568lm
- 4000K 2688lm
REF. 30021/300:
PCB-LED 51,6W 700mA CRI > 90
- 2700K 3699lm
- 3000K 3852lm
- 4000K 4032lm
DRIVER (Depends on the sum of meters of the total profiles)
DRIVER (Según la suma de metros del total de perfiles)
KIT 30021/1:
For 125cm and 200cm / Para 125cm y 200cm
KIT 30021/2:
For 250cm to 475cm / Para 250cm a 475cm
KIT 30021/3:
For 500cm to 625cm / Para 500cm a 625cm
KIT 30021/4:
For 650cm to 900cm / Para 650cm a 900cm
D dim DALI
P dim PUSH
dim Casambi
C
Ask factory for customization / Personalización consultar con fábrica
* Dimmable up to 8,5 m / Regulable hasta 8,5 m
NOTE / NOTA:
Max. 4 profiles per KIT not exceeding a total of 9 meters.
Máximo 4 perfiles por KIT que no superen el total de 9 metros.
OLÉ LIGHTING 2025
AVATA R P O P
Metal Collection
Long. 300 cm
Max.
60 cm
Max.
60 cm
