TECHNICAL CATALOGUE | 143
142 | TECHNICAL CATALOGUE
DOWNLIGHTS - COMMERCIAL
WATT
CCT
BEAM
LUMEN
CODES
REFLECTOR
DRIVER
20W
3000K
20O
1337Lm
9030870 + 9030871
9030873
On/Off Included
Dali 9621523
Triac 9844002
40O
1337Lm
9030870
60O
1337Lm
9030870 + 9030872
WALLWASH 45O
1337Lm
9030870 + 9030885
4000K
20O
1409Lm
9030870 + 9090874 + 9030871
40O
1409Lm
9030870 + 9090874
60O
1409Lm
9030870 + 9090874 + 9030872
WALLWASH 45O
1409Lm
9030870 + 9090874 + 9030885
28W
3000K
20O
1827Lm
9030875 + 9030876
9030878
On/Off Included
Dali 9621521
Triac 9844002
40O
1827Lm
9030875
60O
1827Lm
9030875 + 9030877
WALLWASH 45O
1827Lm
9030875 + 9030886
4000K
20O
2060Lm
9030875 + 9030879 + 9030876
40O
2060Lm
9030875 + 9030879
60O
2060Lm
9030875 + 9030879 + 9030877
WALLWASH 45O
2060Lm
9030875 + 9030879 + 9030886
40W
3000K
20O
2640Lm
9030880 + 9030881
9030883
On/Off Included
Dali 9621522
40O
2640Lm
9030880
60O
2640Lm
9030880 + 9030882
WALLWASH 45O
2640Lm
9030880 + 9030887
4000K
20O
2720Lm
9030880 + 9030884 + 9030881
40O
2720Lm
9030880 + 9030884
60O
2720Lm
9030880 + 9030884 + 9030882
WALLWASH 45O
2720Lm
9030880 + 9030884 + 9030887
WATT
CCT
BEAM
LUMEN
CODES
REFLECTOR
DRIVER
28W
3000K
20O
1921Lm
9030888 + 9030871
9030873
On/Off Included
Dali 9621521
Triac 9844002
40O
1921Lm
9030888
60O
1921Lm
9030888 + 9030872
WALLWASH 45O
1921Lm
9030888 + 9030885
4000K
20O
1921Lm
9030888 + 9090874 + 9030871
40O
1921Lm
9030888 + 9090874
60O
1921Lm
9030888 + 9090874 + 9030872
WALLWASH 45O
1921Lm
9030888 + 9090874 + 9030885
36W
3000K
20O
2477Lm
9030889 + 9030876
9030878
On/Off Included
Dali 9621522
40O
2477Lm
9030889
60O
2477Lm
9030889 + 9030877
WALLWASH 45O
2477Lm
9030889 + 9030886
4000K
20O
2477Lm
9030889 + 9030879 + 9030876
40O
2477Lm
9030889 + 9030879
60O
2477Lm
9030889 + 9030879 + 9030877
WALLWASH 45O
2477Lm
9030889 + 9030879 + 9030886
12.5
8.5
11.5 cm
10.5
7.4
9.5 cm
15.5
10
14.5 cm
17.6 cm
14.3 cm
15.9
10.4
19
12.1
DOWNLIGHTS - COMMERCIAL
WATT
CCT
BEAM
LUMEN
CODES
REFLECTOR
DRIVER
28W
3000K
20O
1921Lm
9030890 + 9030871
9030873
On/Off Included
Dali 9621521
Triac 9844002
40O
1921Lm
9030890
60O
1921Lm
9030890 + 9030872
WALLWASH 45O
1921Lm
9030890 + 9030885
4000K
20O
1921Lm
9030890 + 9090874 + 9030871
40O
1921Lm
9030890 + 9090874
60O
1921Lm
9030890 + 9090874 + 9030872
WALLWASH 45O
1921Lm
9030890 + 9090874 + 9030885
56W
3000K
20O
3842Lm
9030891 + 2x9030876
2x9030878
On/Off Included
Dali 2x9621521
Triac 2x9844002
40O
3842Lm
9030891
60O
3842Lm
9030891 + 2x9030877
WALLWASH 45O
3842Lm
9030891 + 2x9030886
4000K
20O
3842Lm
9030891 + 2x9030879 + 2x9030876
40O
3842Lm
9030891 + 2x9030879
60O
3842Lm
9030891 + 2x9030879 + 2x9030877
WALLWASH 45O
3842Lm
9030891 + 2x9030879 + 2x9030886
84W
3000K
20O
5763Lm
9030892 + 3x9030881
3x9030883 On/Off Included
Dali 3x9621522
40O
5763Lm
9030892
60O
5763Lm
9030892 + 3x9030882
WALLWASH 45O
5763Lm
9030892 + 3x9030887
4000K
20O
5763Lm
9030892 + 3x9030884 + 3x9030881
40O
5763Lm
9030892 + 3x9030884
60O
5763Lm
9030892 + 3x9030884 + 3x9030882
WALLWASH 45O
5763Lm
9030892 + 3x9030884 + 3x9030887
112W
3000K
20O
7684Lm
9030893 + 4x9030881
4x9030883 On/Off Included
Dali 4x9621522
40O
7684Lm
9030893
60O
7684Lm
9030893 + 4x9030882
WALLWASH 45O
7684Lm
9030893 + 4x9030887
4000K
20O
7684Lm
9030893 + 4x9030884 + 4x9030881
40O
7684Lm
9030893 + 4x9030884
60O
7684Lm
9030893 + 4x9030884 + 4x9030882
WALLWASH 45O
7684Lm
9030893 + 4x9030884 + 4x9030887
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3 UGR <16
DRIVER
INCLUDED
14
14
12.68
27.68
27.68
12.68
14
41.37
12.68
27.68
12.68
14
ADJUSTABLE TRIM
TRIM
12.9X12.9
cm
26.3X12.9
cm
26.6X26.6
cm
40.2X12.9
cm
