DOWNLIGHTS - LINEAR
Stealth
PRO
The Linear Stealth Downlight features
special lenses designed for accent lighting
and
illuminating
spaces
where
the
visibility of the light source should be
minimal. Its discreet design and precise
optics make it perfect for creating
subtle yet impactful lighting effects.
Available in both trim and trimless
versions, with black and white finishes,
the range also includes an adjustable
option
for
added
flexibility—offering
a sleek, versatile solution for refined
architectural lighting.
DOWNLIGHTS - LINEAR
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
IOUT
DRIVER
9040117
5W
3000K
420Lm
L 6.4 W 2.8 H 3.8
220-240Vac
-
On/Off Included
Dali 9844145
Triac 9621520 (remote)
9040116
5W
3000K
420Lm
L 6.4 W 2.8 H 3.8
220-240Vac
-
9040119
8W
3000K
700Lm
L 10 W 2.8 H 3.8
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
9040118
8W
3000K
700Lm
L 10 W 2.8 H 3.8
220-240Vac
-
9040121
15W
3000K
1400Lm
L 19 W 2.8 H 3.8
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
9040120
15W
3000K
1400Lm
L 19 W 2.8 H 3.8
220-240Vac
-
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90 STEP <3
28
O UGR <19
DRIVER
INCLUDED
TRIAC
/ DALI
TRIM
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
IOUT
DRIVER
9040122
5W
3000K
420Lm
L 8.4 W 4.8 H 4
220-240Vac
-
On/Off Included
Dali 9844145
Triac 9621520 (remote)
9040123
8W
3000K
700Lm
L 12 W 4.8 H 4
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
9040124
15W
3000K
1400Lm
L 21 W 4.8 H 4
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90 STEP <3
28
O UGR <19
DRIVER
INCLUDED
TRIAC
/ DALI
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
IOUT
DRIVER
9040125
5W
3000K
420Lm
L 7.3 W 4.5 H 4.8
220-240Vac
-
On/Off Included
Dali 9844145
Triac 9621520 (remote)
9040126
8W
3000K
700Lm
L 10.9 W 4.5 H 4.8
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
9040127
15W
3000K
1400Lm
L 20.1 W 4.5 H 4.8
220-240Vac
-
On/Off Included
Dali 9621523
Triac 9844019 (remote)
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90 STEP <3
28
O UGR <19
DRIVER
INCLUDED
TRIAC
/ DALI
TRIMLESS
ADJUSTABLE TRIM
8.4
6.1
4.8
2.5
4
6.4
2.8
2.8
3.8
10
2.8
2.8
3.8
19
2.8
2.8
3.8
12
9.7
4.8
2.5
4
21
18.7
4.8
2.5
4
7.3
5.9
4.5
2.3
4.8
10.9
9.5
4.5
2.3
4.8
20.1
18.5
4.5
2.3
4.8
30o
EASY INSTALLATION
DRIVER FITS INTO
CUT-OUT DIAMETER
& CAN BE REPLACED
19.5X3.9
cm
19.8X3
cm
18.6X2.4
cm
9.6X2.4
cm
6X2.4
cm
10.5X3.9
cm
10.8X3
cm
6.9X3.9
cm
7.2X3
cm
