TECHNICAL CATALOGUE | 355
354 | TECHNICAL CATALOGUE
LIGHTING SYSTEMS - IMAGINE
LIGHTING SYSTEMS - IMAGINE
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492842
8W
3000K
591Lm
D 4 H 40
48Vdc
On/Off
9492843
8W
3000K
591Lm
D 4 H 70
48Vdc
On/Off
9492841
8W
3000K
591Lm
D 4 H 70
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
24
O UGR <12
DRIVER
EXCLUDED
4
10
40
4
70
10
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492835
Up:8W, Down:16W
3000K
Up:321Lm Down:1287Lm
L 108.3 W 2.1 H 3.9
48Vdc
On/Off
9492837
Up:8W, Down:16W
3000K
Up:349Lm Down:1396Lm
L 108.3 W 2.1 H 3.9
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
36
O UGR <10
DRIVER
EXCLUDED
3.9
2.1
108.3
50
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492834
Up:8W, Down:16W
3000K
Up:295Lm, Down:737Lm
L 108.3 W 2.1 H 3.7
48Vdc
On/Off
9492836
Up:8W, Down:16W
3000K
Up:339Lm, Down:783Lm
L 108.3 W 2.1 H 3.7
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
60
O
DRIVER
EXCLUDED
3.7
2.1
108.3
50
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492817
24W
3000K
1877Lm
L 108.3 W 2.1 H 3.7
48Vdc
On/Off
9492818
24W
3000K
1938Lm
L 108.3 W 2.1 H 3.7
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
36
O UGR <10
DRIVER
EXCLUDED
3.7
2.1
108.3
50
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492873
24W
3000K
938Lm
L 108.3 W 2.1 H 3.9
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
60
O
DRIVER
EXCLUDED
3.9
2.1
108.3
50
• Indirect & Direct Light
• UGR <13
• Microprismatic Lens
• UGR <13
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492833
24W
3000K
914Lm
L 108.3 W 2.1 H 14.5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
60
O
DRIVER
EXCLUDED
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9492816
24W
3000K
1680Lm
L 108.3 W 2.1 H 14.5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90
24
O UGR <10
DRIVER
EXCLUDED
108.3
2.1
14.5
3.7
108.3
2.1
14.5
3.7
• Rotatable Verticaly
• Rotatable Verticaly
