TECHNICAL CATALOGUE | 335
334 | TECHNICAL CATALOGUE
LIGHTING SYSTEMS - SYMMETRIC
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9680113
6W
3000K
206Lm
D 4 H 20.3
24Vdc
Triac
IP20
YEARS
>30.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
24
O
DRIVER
EXCLUDED
4.2
100
20.3
4
16.7
LIGHTING SYSTEMS - SYMMETRIC
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9680192
5W
3000K
240Lm
D 15 H 15.8
24Vdc
Triac
9680193
7W
3000K
280Lm
D 19.7 H 20.2
24Vdc
Triac
IP65
YEARS
>30.000
HOURS IK04
PMMA
CRI
>90 STEP <3 360
O
DRIVER
EXCLUDED
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9680195
14W
3000K
335Lm
D 1.8 H 150
24Vdc
Triac
9680196
27W
3000K
954Lm
D 1.8 H 300
24Vdc
Triac
IP65
YEARS
>30.000
HOURS IK04 Silicone
CRI
>90 STEP <3 360
O
DRIVER
EXCLUDED
15.8
15
20.2
19.7
2.6
8
1.8
150 / 300
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9680217
12W
3000K
667Lm
D 9.1 H 9.75
24Vdc
Triac
IP65
YEARS
>30.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
24
O UGR <19
DRIVER
EXCLUDED
9.1
9.75
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9680212
7W
3000K
275Lm
D 10 H 14.2
24Vdc
Triac
9680207
7W
2700K - 6500K
284Lm
D 10 H 14.2
48Vdc
Dali
IP20
YEARS
>30.000
HOURS IK04
Acrylic
CRI
>90 STEP <3
100
O
DRIVER
EXCLUDED
4.2
10
16.7
9680198
Accessory for hanging
OPTIONAL ACCESSORIES
8
2.6
• Compatible for
Outdoor use
• Compatible for
Outdoor use
• Compatible for
Outdoor use
