One L
WITH TRIM
TRIMLESS
ADJUSTABLE
ADJUSTABLE
ADJUSTABLE
ADJUSTABLE
ADJUSTABLE
RFW
TRF
TGB
TSF
RAW
TRA
GB
SF
RFB
RAB
6.8 cm
7.5 cm
7.5 cm
6.8 cm
6.8 cm
6.8 cm
6.8 cm
7.5 cm
11
12.3
6.6
12.3
7.5
11
12.3
7.1
13.5
8.2
12.1
8.3
12.4
7.5
12.1
8.3
12.4
7.5
11
12.4
6.6
11
12.4
6.6
WATT
WATT
CCT
CCT
FLUX
FLUX
DIMENSIONS (cm)
DIMENSIONS (cm)
VOLTAGE
VOLTAGE
20
20
2700K
2700K
2200Lm
2200Lm
500 mA
500 mA
36Vdc
36Vdc
20
20
3000K
3000K
2250Lm
2250Lm
500 mA
500 mA
36Vdc
36Vdc
20
20
4000K
4000K
2365Lm
2365Lm*
500 mA
500 mA
36Vdc
36Vdc
IP20
IP54
5 YEARS
>50.000
HOURS IK05 Aluminium
CRI
>90 STEP <3
DRIVER
EXCLUDED
Technical Specification
Wattage
20
CCT
27 – 2700K
30 – 3000K
40 – 4000K
Lenses
24 – 24o Beam Angle
30 – 30o Beam Angle
40 – 40o Beam Angle
55 – 55o Beam Angle
Filters
N – No Filter
H – Honeycomb
L – Linear Spread
SO – Soft Beam
AG – Anti-Glare Snoot
54 – IP54 Filter
Code
XX
-
-
-
-
-
XX(X)
X(X)
XX
X(X)
XX(X)
Example 2
20-27-RFW-CB-24-L Triac
Example 1
120-27-GB-24-N Dali
AFW1
AAW1
AFB1
AAB1
Trims
RFW – Round Fixed White
RFB – Round Fixed Black
RAW – Round Adj. White
RAB – Round Adj. Black
AFW – Aluminum Fixed White1
AFB – Aluminum Fixed Black1
AAW – Aluminum Adj. White1
AAB – Aluminum Adj. Black1
SF – Square Fixed
GB – Gible1
TRF – Trimless Round Fixed
TRA – Trimless Round Adj.
TGB – Trimless Gible1
TSF – Trimless Square Fixed
1These options are not compatible with inner trim and filters.
Please leave blank the inner trim option in the code making.
See example.
2Only compatible with round fix trims.
3Only compatible with round adjustable trims.
4Only compatible with square trims.
Dim Options
On/Off 9540264
Triac 9844002
Dali 9621523
7.5X7.5
cm
7.5X7.5
cm
Inner Trim
W – Matt White
B – Matt Black
CB – Chrome Black
S – Chrome Silver
G – Chrome Gold
RH - Round Pinhole2
OH - Oval Pinhole3
SH - Square Pinhole4
Inner Trims
Fully Aluminium Trims
(including inner trim)
Matt
White
Chrome
Gold
Chrome
Black
Chrome
Gold
Matt
Black
Chrome
Silver
Matt
White
Chrome
Silver
Pinholes
Oval
Square
CODE
DIMENSIONS (mm)
9090096
D70 x D115 x 3
Trimless Drilling Accessory
Round
Filters
Anti-Glare
Snoot
Soft
Beam
Linear
Spread
Honeycomb
IP54
Chrome
Black
*For complete product using chrome silver inner trim
