TECHNICAL CATALOGUE | 285
284 | TECHNICAL CATALOGUE
LOW VOLTAGE TRACKS - BREDA
116
106.4
2.2
5.5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136201
24W
3000K
1165Lm
L 106 W 2.2 H1 5.4 H2 116
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
120
O UGR <19
DRIVER
EXCLUDED
LOW VOLTAGE TRACKS - BREDA
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136195
5W
3000K
200Lm
D 5 H 100
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
15
O UGR <19
DRIVER
EXCLUDED
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136196
5W
3000K
230Lm
D 4.5 H 60
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
36
O UGR <16
DRIVER
EXCLUDED
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136197
5W
3000K
138Lm
D 1.5 H 150
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
36
O UGR <16
DRIVER
EXCLUDED
100
4.7
5
60
6.8
4.5
150
60
1.5
116
106.4
2.2
5.5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136200
24W
3000K
1800Lm
L 106 W 2.2 H1 5.4 H2 116
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
30
O UGR <19
DRIVER
EXCLUDED
Lighting
Modules
Flexible
• Flexible
• Flexible
• Flexible
• Flexible
• Flexible
