TECHNICAL CATALOGUE | 229
228 | TECHNICAL CATALOGUE
LOW VOLTAGE TRACKS - ULTRA SLIM
ZOOM IN
ZOOM OUT
15°-36°
ROTATE
IN EVERY
DIRECTION
360°
LOW VOLTAGE TRACKS - ULTRA SLIM
2.5
4.5
18
2.5
18
5.5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9080010
5W
3000K
363Lm
L 4.5 W 18 H 2.5
48Vdc
On/Off
9010305
5W
3000K
363Lm
L 4.5 W 18 H 2.5
48Vdc
Dali
9010312
5W
4000K
363Lm
L 4.5 W 18 H 2.5
48Vdc
On/Off
9010103
5W
3000K
363Lm
L 4.5 W 18 H 2.5
48Vdc
On/Off
9010314
5W
4000K
363Lm
L 4.5 W 18 H 2.5
48Vdc
On/Off
9080020
10W
3000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
On/Off
9010306
10W
3000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
Dali
9010313
10W
4000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
On/Off
9010104
10W
3000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
On/Off
9010320
10W
3000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
Dali
9010315
10W
4000K
730Lm
L 5.5 W 18 H 2.5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3 15
O -36
O UGR <19
DRIVER
EXCLUDED
100
5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136202
5W
3000K
499Lm
D 5 H 100
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
15
O UGR <19
DRIVER
EXCLUDED
60
4.5
150
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136204
5W
3000K
139Lm
D 1.5 H 150
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
36
O UGR <19
DRIVER
EXCLUDED
6.8
4.5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9136203
5W
3000K
444Lm
D 4.5 H 60
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
36
O UGR <19
DRIVER
EXCLUDED
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9010105
5W
3000K
320Lm
D 4.5 H 5
48Vdc
On/Off
9010106
10W
3000K
700Lm
D 5.5 H 5.5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
30
O UGR <19
DRIVER
EXCLUDED
5
5.5
4.5
5.5
• Adj. Beam Angle
15o-36o
