LOW VOLTAGE TRACKS - ULTRA SLIM
CODE
DESCRIPTION
DIMENSIONS (cm)
9550020
1m Track (Max 300Watt)
100
4.1
2.2
9550014
2m Track (Max 300Watt)
200
4.1
2.2
9550070
Vertical 90°
Electrical / Mechanical Connector
2.2
5.1
5.1
9550060
Horizontal 90°
Electrical / Mechanical Connector
4.1
4.5
4.5
9550090
End Cap
2.2 0.15
4.1
9560040
Connector Tube
2.3
37.3
9560030
Connector Tube with Power Connector
6
1.75
1.1
6.5
37.3
Ultra Slim
SURFACE - PENDANT APPLICATION
TRACKS & ACCESSORIES
LINEAR TRACKS
CONNECTORS
CODE
DESCRIPTION
DIMENSIONS (cm)
9560020
Power Connector
1.75
1.1
6.5
9560010
Electrical / Mechanical Connector
1.75
1.1
6.5
6.5
CODE
DESCRIPTION
DIMENSIONS (cm)
9560035
Dali Power Connector
1.75
1.1
6.5
9560011
Dali Electrical / Mechanical Connector
1.75
1.1
6.5
6.5
9560012
Dali Electrical Connector 10cm
for 9550070 & 9550060
1.75
1.1
6.5
6.5
On/Off
Dali
POWER
FEED
POWER FEED
CONNECTOR
CONNECTOR
LOW VOLTAGE TRACKS - ULTRA SLIM
Remote Drivers
CODE
DESCRIPTION
DIMENSIONS (cm)
IP20
9621500
75 Watt, 220-240VAC, 48VDC 1.6A
L 9.9 W 9.7 H 3
9621501
100 Watt, 220-240VAC, 48VDC 2.3A
L 12.9 W 9.7 H 3
9621502
150 Watt, 220-240VAC, 48VDC 3.3A
L 15.9 W 9.7 H 3
9621503
200 Watt, 220-240VAC, 48VDC 4.4A0
L 21.5 W 11.5 H 3
IP67
9621504
75 Watt, 100-240VAC, 48VDC 1A
L 14 W 6.3 H 3.2
9621505
100 Watt, 100-240VAC, 48VDC 1.1A
L 14 W 6.3 H 3.2
9621506
150 Watt, 100-240VAC, 48VDC 2A
L 18 W 6.3 H 3.55
9621507
200 Watt, 100-240VAC, 48VDC 2.4A
L 19.9 W 6.3 H 3.55
9010130
Dali Bus 100-240V, Iout 220mA
Optional Accessories
4.1
2.2
1.2
4.1
2.2
1.2
