TECHNICAL CATALOGUE | 217
216 | TECHNICAL CATALOGUE
LOW VOLTAGE TRACKS - MINIMAL
LOW VOLTAGE TRACKS - MINIMAL
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810073
6W
2700K
511Lm
D 4.2 H 4.7
48Vdc
On/Off
9844132
6W
3000K
511Lm
D 4.2 H 4.7
48Vdc
On/Off
9810074
7W
2700K
706Lm
D 5.2 H 6.2
48Vdc
On/Off
9844133
7W
3000K
706Lm
D 5.2 H 6.2
48Vdc
On/Off
9844134
7W
3000K
706Lm
D 5.2 H 6.2
48Vdc
Dali
9810043
7W
3000K
706Lm
D 5.2 H 6.2
48Vdc
On/Off
9810044
7W
3000K
706Lm
D 5.2 H 6.2
48Vdc
Dali
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
30
O UGR <19
DRIVER
EXCLUDED
0.7
4.2
4
1.1
16.1
0.7
5.6
5.4
1.1
16.1
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810076
7W
2700K
397Lm
L 4.8 W 4.8 H 4
48Vdc
On/Off
9844135
7W
3000K
397Lm
L 4.8 W 4.8 H 4
48Vdc
On/Off
9810075
7W
2700K
397Lm
L 4.8 W 4.8 H 4
48Vdc
On/Off
9810045
7W
3000K
397Lm
L 4.8 W 4.8 H 4
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
30
O UGR <19
DRIVER
EXCLUDED
4.8
4.8
1.1
0.7
4
16.1
ONLY FOR SURFACE TRACK (9844099, 9810020, 9844100, 9810021)
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810079
5W
2700K
380Lm
D 10 H 10.5
48Vdc
On/Off
9810056
5W
3000K
380Lm
D 10 H 10.5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3 360
O
DRIVER
EXCLUDED
15
10
10.5
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9040130
10W
3000K
900Lm
D 8.7 H 8.4
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK03 Aluminium
CRI
>90 STEP <3
36
O UGR <19
DRIVER
EXCLUDED
16.1
7.5
8.7
