TECHNICAL CATALOGUE | 215
214 | TECHNICAL CATALOGUE
LOW VOLTAGE TRACKS - MINIMAL
LOW VOLTAGE TRACKS - MINIMAL
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9844124
3W
3000K
162Lm
D 2.2 H 4.8
48Vdc
On/Off
9844125
5W
3000K
488Lm
D 2.8 H 6
48Vdc
On/Off
9810065
7W
2700K
572Lm
D 3.5 H 7.2
48Vdc
Dali
9844126
7W
3000K
572Lm
D 3.5 H 7.2
48Vdc
On/Off
9844127
7W
3000K
572Lm
D 3.5 H 7.2
48Vdc
Dali
9810064
7W
2700K
572Lm
D 3.5 H 7.2
48Vdc
Dali
9810038
7W
3000K
572Lm
D 3.5 H 7.2
48Vdc
Dali
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
35
O UGR <19
DRIVER
EXCLUDED
0.7
10
2.2
4.8
0.7
10
2.8
6
0.7
10
3.5
7.2
90o
335o
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810067
5W
2700K
483Lm
D 3 H 5
48Vdc
On/Off
9844128
5W
3000K
483Lm
D 3 H 5
48Vdc
On/Off
9844129
5W
3000K
483Lm
D 3 H 5
48Vdc
Dali
9810066
5W
2700K
483Lm
D 3 H 5
48Vdc
On/Off
9810068
5W
2700K
483Lm
D 3 H 5
48Vdc
Dali
9810039
5W
3000K
483Lm
D 3 H 5
48Vdc
On/Off
9810040
5W
3000K
483Lm
D 3 H 5
48Vdc
Dali
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
30
O UGR <19
DRIVER
EXCLUDED
0.7
5
4
3
10
365o
180o
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810070
6W
2700K
456Lm
D 5 H 5
48Vdc
On/Off
9844130
6W
3000K
456Lm
D 5 H 5
48Vdc
On/Off
9810069
6W
2700K
456Lm
D 5 H 5
48Vdc
On/Off
9810041
6W
3000K
456Lm
D 5 H 5
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
26
O
DRIVER
EXCLUDED
0.7
4.5
7.6
3
10.4
180o
365o
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810050
6W
3000K
440Lm
D 2.4 H 40
48Vdc
On/Off
9810051
6W
3000K
440Lm
D 2.4 H 40
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3
36
O UGR <19
DRIVER
EXCLUDED
40
2.4
150
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810081
12W
2700K
716Lm
L 100 W 1.22 H 1
48Vdc
On/Off
9810058
12W
3000K
716Lm
L 100 W 1.22 H 1
48Vdc
On/Off
9810059
24W
3000K
1432Lm
L 200 W 1.22 H 1
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK06 Silicone
CRI
>90 STEP <3
110
O
DRIVER
EXCLUDED
8.5
200
1
8.5
100
1
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810061
6W
2700K
722Lm
L 30 W 1.1 H 0.7
48Vdc
On/Off
9844122
6W
3000K
722Lm
L 30 W 1.1 H 0.7
48Vdc
On/Off
9810060
6W
2700K
722Lm
L 30 W 1.1 H 0.7
48Vdc
On/Off
9810036
6W
3000K
722Lm
L 30 W 1.1 H 0.7
48Vdc
On/Off
9810063
12W
2700K
1346Lm
L 60 W 1.1 H 0.7
48Vdc
On/Off
9844123
12W
3000K
1346Lm
L 60 W 1.1 H 0.7
48Vdc
On/Off
9810062
12W
2700K
1346Lm
L 60 W 1.1 H 0.7
48Vdc
On/Off
9810037
12W
3000K
1346Lm
L 60 W 1.1 H 0.7
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK06
PC
CRI
>90 STEP <3
110
O UGR <19
DRIVER
EXCLUDED
5
30
0.7
1.1
5
60
0.7
1.1
CODE
WATT
CCT
FLUX
DIMENSIONS (cm)
VOLTAGE
DIMMABLE
9810080
5W
2700K
380Lm
D 10 H 129.8
48Vdc
On/Off
9810057
5W
3000K
380Lm
D 10 H 129.8
48Vdc
On/Off
IP20
5 YEARS
>50.000
HOURS IK04 Aluminium
CRI
>90 STEP <3 360
O
DRIVER
EXCLUDED
15
10
129.8
