LOW VOLTAGE TRACKS - MINIMAL
CODE
DESCRIPTION
DIMENSIONS (cm)
9844103
1m Track (Max 200W), Cut-Out: 2cm
100
4
1.1
9810022
9844104
2m Track (Max 200W), Cut-Out: 2cm
200
4
1.1
9810023
9844143
Curved Track 60cm / 90o
9844106
Dali Power Connector Wire 50cm
8.5
50
1.1
0.6
9810024
9844108
Dali Electrical / Mechanical Connector
used to connect rail by rail
1.1
15
0.6
9810025
9844109
Dali Horizontal 90o
Electrical Connector
0.6
8.5
8.5
1.1
9810026
9844111
Horizontal 90o
Mechanical Connector
5
5
1
1.9
4
9810028
9844112
T Electrical Connector
8.5
16
1.1
0.6
9810029
9844114
T Mechanical Connector
4
5
6
1
1.9
9810031
9844115
Dali Vertical 90o
Electrical Connector
1.1
0.6
22
8.5
8.5
9810032
9844117
Vertical 90o
Mechanical Connector
1
1.9
4
4
4
9810034
9844118
End Cap
1
1.1
1.9
9810035
Minimal
RECESS APPLICATION
TRACKS & ACCESSORIES
LINEAR TRACKS
CONNECTORS
CURVE
TRACKS
POWER
FEED
1.1
4
LOW VOLTAGE TRACKS - MINIMAL
CODE
DESCRIPTION
DIMENSIONS (CM)
9810048
Casambi Ready Controller 8 adresses
L 15 W 2.8 H 2
Suggested Casambi Controller
Remote Drivers
1.12
CODE
DESCRIPTION
DIMENSIONS (cm)
IP20
9621500
75 Watt, 220-240VAC, 48VDC 1.6A
L 9.9 W 9.7 H 3
9621501
100 Watt, 220-240VAC, 48VDC 2.3A
L 12.9 W 9.7 H 3
9621502
150 Watt, 220-240VAC, 48VDC 3.3A
L 15.9 W 9.7 H 3
9621503
200 Watt, 220-240VAC, 48VDC 4.4A0
L 21.5 W 11.5 H 3
IP67
9621504
75 Watt, 100-240VAC, 48VDC 1A
L 14 W 6.3 H 3.2
9621505
100 Watt, 100-240VAC, 48VDC 1.1A
L 14 W 6.3 H 3.2
9621506
150 Watt, 100-240VAC, 48VDC 2A
L 18 W 6.3 H 3.55
9621507
200 Watt, 100-240VAC, 48VDC 2.4A
L 19.9 W 6.3 H 3.55
