CONNECTORS
LINEARVERBINDER | LINEAR CONNECTOR
innenliegend / inside
715-0782000000000
VERBINDER RING ZU LINEAR | CONNECTOR RING TO LINEAR
innenliegend / inside
722-068600000000000
VERBINDER RING ZU RING | CONNECTOR RING TO RING
innenliegend / inside
722-068500000000000
L-VERBINDER | L-CONNECTOR
innenliegend / inside
715-0783000000000
AUFBAU L-VERBINDER | SURFACE L-CONNECTOR
aussenliegend / outside
715-0173000000XX0
LOG 50 SYSTEM
ARTIKELNUMMER ERGÄNZEN / COMPLETE CODE
XX = FARBE / COLOUR
G
grey = 40
W
white = 50
S
black = 60
L-VERBINDER AUFBAU / L-CONNECTOR SURFACE
220-240V AC
50/60Hz
MID OUTPUT VERSION
L-VERBINDER EINBAU / L-CONNECTOR RECESSED
220-240V AC
50/60Hz
MID OUTPUT VERSION
HIGH OUTPUT VERSION
HIGH OUTPUT VERSION
ARTIKELNUMMER ERGÄNZEN / COMPLETE CODE
C = ABDECKUNG /COVER
WW = LICHTFARBE / LIGHT COLOUR
XX = FARBE / COLOUR
Y = DIMMBAR / DIMMABLE
opal = 1
LED 2700K = 13 CRI>80
G
grey = 40
S
switchable = 0
microprismatic foil = 2
LED 3000K = 19 CRI>80
W
white = 50
D
DALI dimm. = d
LED 4000K = 14 CRI>80
S
black = 60
SYS 7W
lm
715-011710C0WWXXY
840
860
860
800
820
820
SYS 7W
lm
715-031710C0WWXXY
840
860
860
800
820
820
SYS 13W
lm
715-011730C0WWXXY
1660
1710
1710
1580
1620
1620
SYS 13W
lm
715-031730C0WWXXY
1660
1710
1710
1580
1620
1620
CONNECTORS
311
311
52
65
317
317
64
62
1 - 25mm
1 - 25mm
95mm
95mm
EINBAU L-VERBINDER | RECESSED L-CONNECTOR
aussenliegend / outside
715-0373000000XX0
62
188
64
188
106
65
52
182
182
100
