LOG OUT 2.1 PROFIL / PROFILE
Abdeckungen, Lichteinsätze und Zubehör separat ordern
order covers, light inserts and components separately
728-195010000500
W
L: 4500mm
728-195010000600
S
L: 4500mm
728-195010000800
AE
L: 4500mm
728-195000000500
W
per Laufmeter / per running meter
728-195000000600
S
per Laufmeter / per running meter
728-195000000800
AE
per Laufmeter / per running meter
ENDDECKEL-SET / END PIECE SET
Set 2 Stk. inkl. Erdungskabel / set 2 pcs. incl. ground cable
728-192000000500 W 728-192000000600 S
728-192000000800 AE
LOG IN 2.1 PROFIL / PROFILE
Abdeckungen, Lichteinsätze und Zubehör separat ordern
order covers, light inserts and components separately
728-395010000500
W
L: 4500mm
728-395010000600
S
L: 4500mm
728-395010000800
AE
L: 4500mm
728-395000000500
W
per Laufmeter / per running meter
728-395000000600
S
per Laufmeter / per running meter
728-395000000800
AE
per Laufmeter / per running meter
ENDDECKEL-SET / END PIECE SET
Set 2 Stk. inkl. Erdungskabel / set 2 pcs. incl. ground cable
728-392000000500 W 728-392000000600 S
728-392000000800 AE
EINBAUBÜGEL / MOUNTING BRACKETS
max. Befestigungsdistanz / max. mounting distance: 900mm
728-3980000
für Deckenstärke 0 - 20mm / for ceiling thickness 0 - 20mm
LOG IN TRIMLESS 2.1 PROFIL / PROFILE
Abdeckungen, Lichteinsätze und Zubehör separat ordern
order covers, light inserts and components separately
728-4950100
A
L: 4500mm
728-4950000
A
per Laufmeter / per running meter
ENDDECKEL-SET FÜR / END PIECE SET
Set 2 Stk. inkl. Erdungskabel / set 2 pcs. incl. ground cable
728-4920000
A
LOG 2.1 SYSTEM
Design: INHOUSE
LOG OUT 2.1 PROFILE
LOG OUT 2.1 CONNECTORS
90
76
90
ET 130
92
76
122
86
ET 100
Deckenstärke: 12,5mm
Ceiling thickness 12,5mm
10
LOG OUT 2.1 90º ECKVERBINDER / 90º JUNCTION
Beleuchtet, durchgangsverdrahtet 1,5mm2, steckfertig, inkl. Verbindungsleitungen
Illuminated, through wired 1,5mm2, ready to plug in, incl. connector cable
Achtung: Lumenwerte inkl. Abdeckung
Attention: Lumendata incl. cover
HIGH EFFICIENCY
W2
W3
W4
728-10500111WX0Y OPAL
SYS 9W
990lm
1020lm
1020lm
728-10500181WX0Y MICROPRISMA SYS 9W
970lm
990lm
990lm
HIGH OUTPUT
W2
W3
W4
728-10500311WX0Y OPAL
SYS 17W 1910lm
1960lm
1960lm
728-10500381WX0Y MICROPRISMA SYS 17W 1870lm
1920lm
1920lm
LOG IN 2.1 90º ECKVERBINDER / 90º JUNCTION
Beleuchtet, durchgangsverdrahtet 1,5mm2, steckfertig, inkl. Verbindungsleitungen
Illuminated, through wired 1,5mm2, ready to plug in, incl. connector cable
Achtung: Lumenwerte inkl. Abdeckung
Attention: Lumendata incl. cover
HIGH EFFICIENCY
W2
W3
W4
728-30500111WX0Y OPAL
SYS 9W
990lm
1020lm
1020lm
728-30500181WX0Y MICROPRISMA SYS 9W
970lm
990lm
990lm
HIGH OUTPUT
W2
W3
W4
728-30500311WX0Y OPAL
SYS 17W 1910lm
1960lm
1960lm
728-30500381WX0Y MICROPRISMA SYS 17W 1870lm
1920lm
1920lm
Inkl. opaler oder microprismatischer Abdeckung
Incl. opal or microprismatic cover
Inkl. opaler oder microprismatischer Abdeckung
Incl. opal or microprismatic cover
direkt strahlend
direct beam
direkt strahlend
direct beam
326
326
76
90
ARTIKELNUMMER ERGÄNZEN / COMPLETE CODE
X = FARBE PROFIL / COLOUR PROFILE
W white = 5
S black = 6
AE aluminium anodized = 8
Y = DIMMBAR / DIMMABLE
S switchable = 0
D DALI dimm = d
W = LICHTFARBE / LIGHT COLOUR
W2 LED 2700K = 3
W3 LED 3000K = 9
W4 LED 4000K = 4
334
334
92
119
LOG OUT 2.1 90° ECKVERBINDER / 90° JUNCTION
aussenliegend, nicht beleuchtet / out board, no lighting
728-190000000500 W 728-190000000600 S
728-190000000800 AE
LOG IN 2.1 90° ECKVERBINDER / 90° JUNCTION
aussenliegend, nicht beleuchtet / out board, no lighting
728-390000000500 W 728-390000000600 S
728-390000000800 AE
LOG OUT / LOG IN / LOG IN TRIMLESS 2.1 90° ECKVERBINDER / 90° JUNCTION
innenliegend / in board
728-6910000
LOG OUT 2 / LOG IN / LOG IN TRIMLESS 2.1 LINEARVERBINDER / LINEAR JUNCTION
innenliegend / in board
728-6890000
