220-240V AC
50/60Hz
Design: INHOUSE
LED Einbaustrahler · Oberfläche pulverbeschichtet · Strahler 350° drehbar, Leuchtenkopf 35° schwenkbar
Die cast aluminium LED spotlight · surface powder-coated · 350° swiveling and 35° tilting head
Incasso LED in alluminio · superficie verniciata a polveri · girevole a 350° e testa orientabile di 35°
Encassé à LED en aluminium · surface thermolaquée · pivotant à 350 et inclinaison de 35°
IP 20
CODE
LED W / mA
LUMEN
637-00201RRWWXXv2
17 / 500
2150 - 2430
25 / 700
2850 - 3240
Kreisel & Electrics, Rainbach, Austria, Planning/realisation: Ben Elmecker, Photo: Kreisel Electric / Martin Pröll
COMPLETE CODE
RR = BEAM ANGLE
WW = LIGHT COLOUR
XX = COLOUR
spot 17˚ = 01
LED 2700K = 43 PREMIUM CRI>90
grey = 04
medium 24˚ = 02
LED 3000K = 49 PREMIUM CRI>90
W
white = 05
flood 40˚ = 03
LED 4000K = 24 CRI>90
S
black = 06
wide flood 60˚ = 04
asymmetric = 05
G
350°
35°
Ø 85
114
44
LED CONVERTER
mA
DIM
FOR
30-880006
500
not dimmable
2 GO R 17W
30-880206
700
not dimmable
2 GO R 25W
24-127490
500-700
DALI dimmable
2 GO R 17/25W
700-3004
500 - 700
CASAMBI dimmable
2 GO R 17/25W
Ø 165mm
1 - 25mm
144mm
