PROFILE
LIGHT INSERTS
3 CIRCUIT TRACK
PROFILSYSTEM
LÄNGE
FÜR LICHTEINSATZ
PROFILE SYSTEM
LENGHT
FOR LIGHT INSERT
581-2X583
583mm
SYS 2 x 15W
581-2X869
869mm
SYS 2 x 21W
581-2X1155
1155mm
SYS 2 x 27W
581-2X2300
2300mm
SYS 4 x 27W
581-2X3445
3445mm
SYS 6 x 27W
581-2X1440
1440mm
SYS 2 x 34W
581-2X2870
2870mm
SYS 4 x 34W
581-2X4300
4300mm
SYS 6 x 34W
LICHTEINSÄTZE
LÄNGE
SYS
LM
LIGHT INSERTS
LENGHT
SYS
LM
528-20WY
571mm
SYS 15W
1730 - 1830
528-24WY
857mm
SYS 21W
2600 - 2740
528-25WY
1143mm
SYS 27W
3470 - 3660
528-26WY
1428mm
SYS 34W
4340 - 4580
SCHIENE
LÄNGE
TRACK
LENGHT
208-1910510X
1000mm
208-1910520X
2000mm
208-1910530X
3000mm
MONTAGESET
FÜR
MOUNTING SET
FOR
581-09
3 circuit track
Distanz: jede 1000mm - 1 set
distance: every 1000mm - 1 set
PROFIL OBJEKT
LÄNGE
PROFILE OBJECT
LENGHT
581-1X4500
4500mm
60
60
L
4500
144
144
COMPLETE CODE FORPROFILE
X = COLOUR
W
white = 5
S
black = 6
AE
alu anodized = 8
COMPLETE CODE FORPROFILE
X = COLOUR
S
black = 2
W
white = 3
G
grey = 5
COMPLETE CODE FORPROFILE
W = LIGHT COLOUR
Y = DIMMABLE
LED 3000K = 9 CRI>80
LED 4000K = 10 CRI>80
switchable = no addition
DALI dim = code + ddd
L
56
32,5
Zubehör für 3-Phasen Stromschiene: Seite 060-065
Components for 3-cirquit track: page 060-065
Abdeckungen, Lichteinsätze und Zubehör separat ordern
Order covers, light inserts and components separately
COMPLETE CODE FORPROFILE
X = COLOUR
W
white = 5
S
black = 6
AE
alu anodized = 8
COVERS
COMPONENTS
MIKROPRISMA
LÄNGE
MICROPRISMA
LENGHT
528-970583
582mm
528-970869
868mm
528-9701155
1154mm
528-9701440
1439mm
528-9702300
2298mm
528-9702870
2869mm
528-9703445
3443mm
528-9704300
4298mm
528-9704500
4500mm
ALUMINIUMABDECKUNG
LÄNGE
ALUMINIUM COVER
LENGHT
528-27X3200
3200mm
PMMA OPAL
LÄNGE
PMMA OPAL
LENGHT
528-405583
582mm
528-405869
868mm
528-4051155
1154mm
528-4051440
1439mm
528-4052300
2298mm
528-4052870
2869mm
528-4053445
3443mm
528-4054300
4298mm
528-1804500
4500mm
PMMA KLAR
LÄNGE
PMMA CLEAR
LENGHT
581-980583
582mm
528-980869
868mm
528-9801155
1154mm
528-9801440
1439mm
528-9802300
2298mm
528-9802870
2869mm
528-9803445
3443mm
528-9804300
4298mm
528-9804500
4500mm
UGR<19
ABHÄNGUNG
LÄNGE
SUSPENSION
LENGHT
581-041X
max. 3000mm
Distanz: max. 800mm
distance: max. 800mm
EINSPEISEKABEL
DIMENSION
POWER FEED CABLE
DIMENSION
301-k1547b2
3 x 0,75mm / L: 1750mm
301-k1547b1
3 x 0,75mm / L: 3150mm
301-k1627b2
3 x 1,50mm / L: 1750mm
301-k1627b1
3 x 1,50mm / L: 3150mm
301-k1787b2
5 x 0,75mm / L: 1750mm
301-k1787b1
5 x 0,75mm / L: 3150mm
301-k1867b2
5 x 1,50mm / L: 1750mm
301-k1867b1
5 x 1,50mm / L: 3150mm
Transparent, für Baldachin
inkl. Kabelbefestigungsringe
transparent, for canopy
incl. cable fixing rings
BALDACHIN
FARBE
CANOPY
COLOUR
301-212000000400
grey
301-212000000500
white
301-212000000600
black
Einspeisekabel separat ordern
order power feed cable separately
90˚ VERBINDER
LÄNGE
90˚ JUNCTION
LENGHT
581-01X
100mm
inkl. Aluminiumabdeckung
incl. aluminium cover
ERDUNGSSET
EARTHING SET
581-05
LINEARVERBINDER
LÄNGE
LINEAR JUNCTION
LENGHT
581-03
140mm
innenliegend
in board
WANDMONTAGESET
LÄNGE
WALL MOUNTING SET
LENGHT
581-109
140mm
Distanz: je 1000mm - 1 set
distance: every 1000mm - 1 set
ENDDECKEL
SET
END PIECE
SET
581-06X
2 pcs.
inkl. Erdungskabel
incl. ground cable
max. 3000
144
60
2
100
100
60
55,5
140
40
17
122
122
26
