185
Miele cooker hoods
Built-in cooker hoods
Product overview
Model number
DA 1260
Construction type
Built-under hood
•
Operating modes
Type of air guide
Convertible
Recircul. conversion kit (order sep.)
–
Active charcoal filter (order separately)
DKF 18-P
Design
Colour
Stainless steel
User convenience
Slide switch
•
Efficiency and sustainability
Energy efficiency class (A+++ to D)
C
Filter system
Stainless steel grease filters
2
Lighting
LED
•
Number x W
2 x 3 W
Light intensity in Lx
330 lx
Colour temperature in K
3000 Kelvin
Extraction
Air throughput in Level 3 (m³/h)
355
Sound power in Level 3 (dB(A))
64.0
Sound pressure in Level 3 (dB(A))
50.0
Recirculation
Air throughput in Level 3 (m³/h)
195
Sound power in Level 3 (dB(A))
73.0
Sound pressure in Level 3 (dB(A))
59.0
Technical data
Overall height extraction and external
use in mm
–
Overall height recirculation in mm
–
Canopy dimensions (W x H x D) in mm
598 x 125 x 500
Min. height above electric hobs in mm
450
Min. safety distance above gas hobs
in mm
650
Total rated load in kW
0.23
Voltage in V
230
Fuse rating in A
10
Installation notes
Extraction ducting connection at top
•
Extraction ducting connection on side
–
Ø of exhaust duct in mm
150
Optional accessories
Active charcoal filter
Nein
Article colour
Stainless steel
•
