MASIERO
28
29
Bōzu
Struttura in metallo galvanizzato
e verniciato nero opaco. Diffusore
in vetro triplex di Murano bianco
opalino. Illuminazione led.
Galvanized and matt black painted
metal frame. Opaline white Murano
triplex glass diffuser. LED lighting.
Gestell aus galvanisch
beschichtetem Metall, schwarz
matt lackiert. Opalweisser
Triplex-Diffusor aus Muranoglas.
LED Leuchtsystem.
Estructura de metal galvanizado
pintado de negro mate. Difusor de
cristal triplex de Murano blanco
opalino. Iluminación LED.
Structure en métal galvanisé peint
en noir mat. Diffuseur triplex en
verre de Murano blanc opalin.
Éclairage à LED.
КарКас из металла с
гальваничесКим и матово-
черным поКрытием.
рассеиватель из трехслойного
мурансКого стеКла
белого опалового цвета.
светодиодное освещение.
电镀金属灯体结构，刷哑光黑色
漆。蛋白石白色穆拉诺三层玻璃
灯罩。LED 灯。
يليطملاو نفلجملا ندعملا نم لكيه
حئاور عزوم .متعملا دوسلأا نوللاب
ةقبطلا ي�ثيلاثلا وناروم جاجز نم ةيرطع
.ديل ةءاضإ .ن�ينلابولأا ضيبلأا نوللاب
V90 Nero opaco
Matt Black
G26 Oro puro spazzolato
Brushed pure gold
C01 Cuoio marrone
Brown leather*
* ONLY FOR BŌZU S3 LN | S8 OV | S6 OV
DISCOVER MORE
BŌZU S8 OV
W
168 cm / 66.10”
D
72 cm / 27.50”
H
26 cm / 10.20”
STANDARD INTEGRATED LED LIGHTING
UP
48 W CRI>90
3000 K – 5800 NOMINAL LM
DOWN
48 W CRI>90
3000 K – 5800 NOMINAL LM
ON REQUEST
UP
48 W CRI>90
2700 K – 5376 NOMINAL LM
DOWN
48 W CRI>90
2700 K – 5376 NOMINAL LM
DIMMABLE
0-10V
BŌZU S6 OV
W
120 cm / 47.25”
D
72 cm / 27.50”
H
26 cm / 10.20”
STANDARD INTEGRATED LED LIGHTING
UP
36 W CRI>90
3000 K – 4350 NOMINAL LM
DOWN
36 W CRI>90
3000 K – 4350 NOMINAL LM
ON REQUEST
UP
36 W CRI>90
2700 K – 4032 NOMINAL LM
DOWN
36 W CRI>90
2700 K – 4032 NOMINAL LM
DIMMABLE
0-10V
BŌZU C3 RD 40
Ø
HMAX
STANDARD INTEGRATED LED LIGHTING
UP
DOWN
ON REQUEST
UP
DOWN
DIMMABLE
BŌZU S1
Ø
14 cm / 5.50”
H
26 cm / 10.20”
STANDARD INTEGRATED LED LIGHTING
UP
4,7 W CRI>90
3000 K – 725 NOMINAL LM
DOWN
4,7 W CRI>90
3000 K – 725 NOMINAL LM
ON REQUEST
UP
4,7 W CRI>90
2700 K – 672 NOMINAL LM
DOWN
4,7 W CRI>90
2700 K – 672 NOMINAL LM
DIMMABLE
TRIAC
H
Ø
H
D
BŌZU S3 LN
W
160 cm / 63.00”
D
14 cm / 5.50”
H
26 cm / 10.20”
STANDARD INTEGRATED LED LIGHTING
UP
18 W CRI>90
3000 K – 2175 NOMINAL LM
DOWN
18 W CRI>90
3000 K – 2175 NOMINAL LM
ON REQUEST
UP
18 W CRI>90
2700 K – 2016 NOMINAL LM
DOWN
18 W CRI>90
2700 K – 2016 NOMINAL LM
DIMMABLE
0-10V
W
BŌZU TL
Ø
14 cm / 5.50”
H
26 cm / 10.20”
STANDARD INTEGRATED LED LIGHTING
6 W CRI>90
3000 K – 725 NOMINAL LM
ON REQUEST
6 W CRI>90
2700 K – 672 NOMINAL LM
DIMMABLE
OWN BUTTON
H
Ø
BŌZU A1
W
14 cm / 5.50”
D
22 cm / 8.70”
H
31 cm / 12.20”
STANDARD INTEGRATED LED LIGHTING
UP
4,7 W CRI>90
3000 K – 725 NOMINAL LM
DOWN
4,7 W CRI>90
3000 K – 725 NOMINAL LM
ON REQUEST
UP
4,7 W CRI>90
2700 K – 672 NOMINAL LM
DOWN
4,7 W CRI>90
2700 K – 672 NOMINAL LM
DIMMABLE
TRIAC
H
W
D
H
H
W
W
D
D
386627_Masiero_Catalogo-Dimore2025_MONDO201224.indd 28
386627_Masiero_Catalogo-Dimore2025_MONDO201224.indd 28
14/01/25 13:41
14/01/25 13:41
29
Bōzu
BŌZU C5 RD 60
Ø
60 cm / 23.60”
HMAX
160 cm / 63.00”
STANDARD INTEGRATED LED LIGHTING
UP
30 W CRI>90
3000 K – 3625 NOMINAL LM
DOWN
30 W CRI>90
3000 K – 3625 NOMINAL LM
ON REQUEST
UP
30 W CRI>90
2700 K – 3360 NOMINAL LM
DOWN
30 W CRI>90
2700 K – 3360 NOMINAL LM
DIMMABLE
0-10V
BŌZU C7 RD 80
Ø
80 cm / 31.50”
HMAX
160 cm / 63.00”
STANDARD INTEGRATED LED LIGHTING
UP
42 W CRI>90
3000 K – 5075 NOMINAL LM
DOWN
42 W CRI>90
3000 K – 5075 NOMINAL LM
ON REQUEST
UP
42 W CRI>90
2700 K – 4704 NOMINAL LM
DOWN
42 W CRI>90
2700 K – 4704 NOMINAL LM
DIMMABLE
0-10V
BŌZU C3 RD 40
Ø
40 cm / 15.74”
HMAX
160 cm / 63.00”
STANDARD INTEGRATED LED LIGHTING
UP
18 W CRI>90
3000 K – 2175 NOMINAL LM
DOWN
18 W CRI>90
3000 K – 2175 NOMINAL LM
ON REQUEST
UP
18 W CRI>90
2700 K – 2016 NOMINAL LM
DOWN
18 W CRI>90
2700 K – 2016 NOMINAL LM
DIMMABLE
0-10V
H
Ø
H
Ø
H
Ø
