VEGAS S RD12
Ø
12 cm / 4.70”
H
28 cm / 11.00”
3 kg / 7.00 lb
STANDARD INTEGRATED LED LIGHTING
5,4 W CRI>90
3000K - 688 NOMINAL LM
ON REQUEST
5,4 W CRI>90
2700 K – 653 NOMINAL LM
DIMMABLE
NO
VEGAS S RD40
Ø
40 cm / 15.70”
H
40 cm / 15.70”
16 kg / 35.00 lb
STANDARD INTEGRATED LED LIGHTING
33 W CRI>90
3000 K – 3520 NOMINAL LM
ON REQUEST
33 W CRI>90
2700 K – 3355 NOMINAL LM
DIMMABLE
0-10V
VEGAS S RD60
Ø
60 cm / 23.60”
H
40 cm / 15.70”
32 kg / 71.00 lb
STANDARD INTEGRATED LED LIGHTING
55 W CRI>90
3000 K – 5866 NOMINAL LM
ON REQUEST
55 W CRI>90
2700 K – 5591 NOMINAL LM
DIMMABLE
0-10V
VEGAS BIL 90
W
D
H
STANDARD INTEGRATED LED LIGHTING
ON REQUEST
DIMMABLE
VEGAS S RD 60DB
Ø
60 cm / 23.60”
H
50 cm / 19.70”
40 kg / 88.00 lb
STANDARD INTEGRATED LED LIGHTING
55 W CRI>90
3000 K – 5866 NOMINAL LM
ON REQUEST
55 W CRI>90
2700 K – 5591 NOMINAL LM
DIMMABLE
0-10V
VEGAS S RD 90DB
Ø
90 cm / 23.60”
H
50 cm / 19.70”
65 kg / 143.00 lb
STANDARD INTEGRATED LED LIGHTING
92,5 W CRI>90
3000 K – 9866 NOMINAL LM
ON REQUEST
92,5 W CRI>90
2700 K – 9404 NOMINAL LM
DIMMABLE
0-10V
VEGAS S RD 120DB
Ø
120 cm / 47.20”
H
50 cm / 19.70”
90 kg / 198.00 lb
STANDARD INTEGRATED LED LIGHTING
126 W CRI>90
3000 K – 13440 NOMINAL LM
ON REQUEST
126 W CRI>90
2700 K – 12810 NOMINAL LM
DIMMABLE
1-10V
VEGAS S OV85
W
D
H
STANDARD INTEGRATED LED LIGHTING
ON REQUEST
DIMMABLE
VEGAS S VRT70
Ø
H
STANDARD INTEGRATED LED LIGHTING
ON REQUEST
DIMMABLE
Vegas
Struttura in metallo con diffusore
in listelli di vetro effetto roccia
Illuminazione a LED.
Metal frame with diffuser in strips
of rock looking glass. LED lighting.
Gestell aus Metall mit Diffusor aus
Glasleisten, Gestein aussehend.
LED-Beleuchtung.
Estructura de metal con difusor
en listones de cristal efecto roca.
Iluminación LED.
Structure en métal peint avec
diffuseur en bandes de verre effet
roche. Éclairage à LED.
Металлический каркас с
рассеивателем из стекла с
эффектом горного хрусталя.
Светодиодное освещение.
这种灯具有金属结构，而且在灯具外面
有岩石类似的玻璃条们。LED照明。
ي�نيدعم لكيه
حئارشر ي
�في ءوض رشران عم
.يرخص ريرثأت تاذ ةيجاجز
.ديل ةءاضإ
H
Ø
H
Ø
H
Ø
VEGAS S RD40 DB
Ø
40 cm / 15.70”
H
50 cm / 19.70”
22 kg / 49.00 lb
STANDARD INTEGRATED LED LIGHTING
33 W CRI>90
3000 K – 3520 NOMINAL LM
ON REQUEST
33 W CRI>90
2700 K – 3355 NOMINAL LM
DIMMABLE
0-10V
H
Ø
H
Ø
F04
Foglia champagne
Champagne leaf
Hand made glass
DISCOVER MORE
VEGAS S RD90
Ø
90 cm / 35.40”
H
40 cm / 15.70”
50 kg / 110.00 lb
STANDARD INTEGRATED LED LIGHTING
91 W CRI>90
3000 K – 9706 NOMINAL LM
ON REQUEST
91 W CRI>90
2700 K – 9251 NOMINAL LM
DIMMABLE
0-10V
VEGAS S RD120
Ø
120 cm / 47.20”
H
40 cm / 15.70”
68 kg / 150.00 lb
STANDARD INTEGRATED LED LIGHTING
126 W CRI>90
3000 K – 13440 NOMINAL LM
ON REQUEST
126 W CRI>90
2700 K – 12810 NOMINAL LM
DIMMABLE
1-10V
H
Ø
H
Ø
H
H
Ø
Ø
DIMMING CONTROL
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 82
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 82
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 82
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 82
28/04/25 16:04
28/04/25 16:04
83
Vegas
VEGAS S VRT90
Ø
27 cm / 10.60”
H
94 cm / 37.00”
27 kg / 60.00 lb
STANDARD INTEGRATED LED LIGHTING
41 W CRI>90
3000 K – 4373 NOMINAL LM
ON REQUEST
41 W CRI>90
2700 K – 4168 NOMINAL LM
DIMMABLE
0-10V
VEGAS BIL 140
W
135 cm / 53.10”
D
27 cm / 10.60”
H
27 cm / 10.60”
42 kg / 93.00 lb
STANDARD INTEGRATED LED LIGHTING
56 W CRI>90
3000 K – 5973 NOMINAL LM
ON REQUEST
56 W CRI>90
2700 K – 5693 NOMINAL LM
DIMMABLE
0-10V
VEGAS S VRT140
Ø
27 cm / 10.60”
H
135 cm / 53.10”
41 kg / 90.00 lb
STANDARD INTEGRATED LED LIGHTING
56 W CRI>90
3000 K – 5973 NOMINAL LM
ON REQUEST
56 W CRI>90
2700 K – 5693 NOMINAL LM
DIMMABLE
0-10V
VEGAS BIL 180
W
175 cm / 68.90”
D
27 cm / 10.60”
H
27 cm / 10.60”
58 kg / 128.00 lb
STANDARD INTEGRATED LED LIGHTING
72 W CRI>90
3000 K – 7680 NOMINAL LM
ON REQUEST
72 W CRI>90
2700 K – 7320 NOMINAL LM
DIMMABLE
0-10V
VEGAS BIL 90
W
94 cm / 37.00”
D
27 cm / 10.60”
H
27 cm / 10.60”
28 kg / 62.00 lb
STANDARD INTEGRATED LED LIGHTING
41 W CRI>90
3000 K – 4373 NOMINAL LM
ON REQUEST
41 W CRI>90
2700 K – 4168 NOMINAL LM
DIMMABLE
0-10V
VEGAS S VRT180
Ø
27 cm / 10.60”
H
175 cm / 68.90”
58 kg / 128.00 lb
STANDARD INTEGRATED LED LIGHTING
72 W CRI>90
3000 K – 7680 NOMINAL LM
ON REQUEST
72 W CRI>90
2700 K – 7320 NOMINAL LM
DIMMABLE
0-10V
VEGAS S OV85
W
85 cm / 33.50”
D
34 cm / 13.40”
H
40 cm / 15.70”
37 kg / 82.00 lb
STANDARD INTEGRATED LED LIGHTING
58,8 W CRI>90
3000 K – 7570 NOMINAL LM
ON REQUEST
58,8 W CRI>90
2700 K – 7191 NOMINAL LM
DIMMABLE
0-10V
VEGAS S OV120
W
120 cm / 47.20”
D
48 cm / 18.90”
H
40 cm / 15.70”
54 kg / 119.00 lb
STANDARD INTEGRATED LED LIGHTING
87,6 W CRI>90
3000 K – 9344 NOMINAL LM
ON REQUEST
87,6 CRI>90
2700 K – 8906 NOMINAL LM
DIMMABLE
0-10V
VEGAS S OV160
W
160 cm / 63.00”
D
65 cm / 25.60”
H
40 cm / 15.70”
72 kg / 159.00 lb
STANDARD INTEGRATED LED LIGHTING
119 W CRI>90
3000 K – 12693 NOMINAL LM
ON REQUEST
119 W CRI>90
2700 K – 12098 NOMINAL LM
DIMMABLE
0-10V
VEGAS S VRT70
Ø
27 cm / 10.60”
H
67 cm / 26.40”
20 kg / 44.00 lb
STANDARD INTEGRATED LED LIGHTING
21 W CRI>90
3000 K – 2240 NOMINAL LM
ON REQUEST
21 W CRI>90
2700 K – 2135 NOMINAL LM
DIMMABLE
0-10V
