MASIERO
16
17
GIROUETTE S1
W
18 cm / 7.10”
D
18 cm / 7.10”
H
23 cm / 9.00”
1,8 kg / 4.00 lb
STANDARD INTEGRATED LED LIGHTING
4,5 W CRI>90
3000K - 486 NOMINAL LM
ON REQUEST
4,5 W CRI>90
2700 K – 464 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE S3 LN
W
64 cm / 25.20”
D
21 cm / 8.30”
H
21 cm / 8.30”
6 kg / 13.00 lb
STANDARD INTEGRATED LED LIGHTING
13,5 W CRI>90
3000 K – 1458 NOMINAL LM
ON REQUEST
13,5 W CRI>90
2700 K – 1392 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE S6 LN
W
129 cm / 50.80”
D
21 cm / 8.30”
H
21 cm / 8.30”
12 kg / 26.00 lb
STANDARD INTEGRATED LED LIGHTING
27 W CRI>90
3000 K – 2916 NOMINAL LM
ON REQUEST
27 W CRI>90
2700 K – 2784 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE S8 RD
Ø
96,5 cm / 38.00”
H
21 cm / 8.30”
16 kg / 35.00 lb
STANDARD INTEGRATED LED LIGHTING
36 W CRI>90
3000 K – 3888 NOMINAL LM
ON REQUEST
36 W CRI>90
2700 K – 3712 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE S12 RD
Ø
111 cm / 43.70”
H
21 cm / 8.30”
24 kg / 53.00 lb
STANDARD INTEGRATED LED LIGHTING
54 W CRI>90
3000 K – 5832 NOMINAL LM
ON REQUEST
54 W CRI>90
2700 K – 5568 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE A1
W
D
H
STANDARD INTEGRATED LED LIGHTING
ON REQUEST
DIMMABLE
Girouette
Struttura in metallo galvanizzato.
Diffusore in borosilicato oro
dicroico sfumato.
Illuminazione Led.
Galvanized metal structure.
Diffuser in shaded gold dichroic
borosilicate. LED lighting.
Gestell aus galvanisch
beschichtetem Metall. Diffusor aus
Borosilikat - dichroitischem Glas,
Gold Farbverlauf.
LED-Beleuchtung.
Estructura de metal galvanizado.
Difusor en borosilicato dorado
dicroico difuminado.
Iluminación LED.
Structure en métal galvanisé.
Diffuseur en borosilicate or
dichroïque ombré. Éclairage LED.
Металлический каркас с
гальваническим покрытием.
Рассеиватель из дымчатого
золотого дихроичного
боросиликатного стекла.
Светодиодное освещение.
电镀金属灯体结构。渐变双色镀
金硼硅玻璃灯罩。Led 照明。
نم رشران .نفلجم ي�نيدعم لكيه
.نوللا ي�نيانث للظملا ي�بيهذلا تاكيلسروبلا
.ديل ةءاضإ
DISCOVER MORE
H
W
D
H
D
W
H
D
W
GIROUETTE S16 RD
Ø
152,5 cm / 60.00”
H
21 cm / 8.30”
32 kg / 71.00 lb
STANDARD INTEGRATED LED LIGHTING
72 W CRI>90
3000 K – 7776 NOMINAL LM
ON REQUEST
72 W CRI>90
2700 K – 7424 NOMINAL LM
DIMMABLE
1-10V + PUSH
GIROUETTE COMBO S36
Ø
H
STANDARD INTEGRATED LED LIGHTING
ON REQUEST
DIMMABLE
Borosilicato oro
Gold borosilicate
G26 Oro puro spazzolato
Brushed pure gold
H
Ø
Ø
H
H
Ø
H
DIMMING CONTROL
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 16
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 16
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 16
386657_Masiero_Catalogo-Atelier_2025_REV28425.indd 16
28/04/25 16:04
28/04/25 16:04
17
Girouette
GIROUETTE A1
W
18 cm / 7.10”
D
20 cm / 7.90”
H
21 cm / 8.30”
2 kg / 4.00 lb
STANDARD INTEGRATED LED LIGHTING
4,5 W CRI>90
3000 K – 486 NOMINAL LM
ON REQUEST
4,5 W CRI>90
2700 K – 464 NOMINAL LM
DIMMABLE
1-10V + PUSH
H
D
W
GIROUETTE COMBO S36
Ø
152,5 cm / 60.00”
H
87 cm / 34.30”
72 kg / 159.00 lb
STANDARD INTEGRATED LED LIGHTING
162 W CRI>90
3000 K – 17496 NOMINAL LM
ON REQUEST
162 W CRI>90
2700 K – 16704 NOMINAL LM
DIMMABLE
1-10V + PUSH
H
Ø
