Módulo lineal-Linear Module
REFERENCE
K
LED WATT
LUMENS
FINISH
7554
3000K
38W
2650lm
Negro-Black
7555
4000K
38W
2800lm
Negro-Black
UGR<16
220-240V~ 50/60Hz CRI≥ 80
Aluminio-Aluminium
REFERENCE
7556
Tapa lateral con cable fijación-Side cover white with fixing wire
7557
Tapa lateral con cable alimentación y florón-Side cover white with ac wire & rosette
7558
Conexión intermedia con cable fijación-Middle connection white with fixing wire
7559
Conexión intermedia con cable alimentación y florón - Middle connection white with ac wire & rosette
HANOK
by David Villalba
7556
7557
7558
7559
