Indoor
Apliques-Wall lights
30
31
REFERENCE
K
LED WATT
LUMENS
FINISH
7774
3000K
14W
950lm
Blanco-White
7776
3000K
14W
950lm
Negro-Black
7778
3000K
14W
950lm
Arena-Sabbia
7775
4000K
14W
1000lm
Blanco-White
7777
4000K
14W
1000lm
Negro-Black
220-240V~50/60Hz CRI:≥ 80
Aluminio-Aluminium
HANOK
by David Villalba
3000K
14W
4000K
14W
7953
pág. 88
7546
pág. 126
7548
pág. 130
Luminous Intensity Distribution Curve
0
180
90
90
10
10
170
170
20
20
160
160
30
30
150
150
40
40
140
140
50
50
130
130
60
60
120
120
70
70
110
110
80
80
100
100
510
408
306
204
102
Average Diffuse Angle(50%): 107.3°
C0-C180
C90-C270
G0
Unit: cd
The Average Illuminance Effective Figure
Beam Angle:159.4°
Height
Avg./Nadir. ED
iameter / Area
1.0m
11.34/
11.01m / 95.21sq.m
408.75lx
2.0m
2.83/
22.02m / 380.83sq.m
102.19lx
3.0m
1.26/
33.03m / 856.86sq.m
45.42lx
4.0m
0.71/
44.04m / 1523.30sq.m
25.55lx
5.0m
0.45/
55.05m / 2380.16sq.m
16.35lx
6.0m
0.31/
66.06m / 3427.44sq.m
11.35lx
8.0m
0.18/
88.08m / 6093.22sq.m
6.39lx
9.0m
0.14/
99.09m / 7711.73sq.m
5.05lx
10.0m0
.11/
110.10m / 9520.66sq.m
4.09lx
12.0m0
.08/
132.12m / 13709.75sq.m
2.84lx
Flux Out: 1079.30lm
Luminous Intensity Distribution Curve
0
180
90
90
10
10
170
170
20
20
160
160
30
30
150
150
40
40
140
140
50
50
130
130
60
60
120
120
70
70
110
110
80
80
100
100
518
411
312
210
108
Average Diffuse Angle(50%): 107.3°
C0-C180
C90-C270
G0
Unit: cd
The Average Illuminance Effective Figure
Beam Angle:159.4°
Height
Avg./Nadir. ED
iameter / Area
1.0m
11.34/
11.01m / 95.21sq.m
408.75lx
2.0m
2.83/
22.02m / 380.83sq.m
102.19lx
3.0m
1.26/
33.03m / 856.86sq.m
45.42lx
4.0m
0.71/
44.04m / 1523.30sq.m
25.55lx
5.0m
0.45/
55.05m / 2380.16sq.m
16.35lx
6.0m
0.31/
66.06m / 3427.44sq.m
11.35lx
8.0m
0.18/
88.08m / 6093.22sq.m
6.39lx
9.0m
0.14/
99.09m / 7711.73sq.m
5.05lx
10.0m0
.11/
110.10m / 9520.66sq.m
4.09lx
12.0m0
.08/
132.12m / 13709.75sq.m
2.84lx
Flux Out: 1079.30lm
