Technical info
SKOT WALL/CEILING
Ceiling/Wall
Page: 238
Design: LK as
Finish:
Aluminium coloured or graphite with textured surface, powder coated.
Material:
Diffuser: Injection moulded clear polycarbonate or injection moulded
opal polycarbonate.
Base/cross guard: Die cast aluminium.
Weight:
Max. 2.5kg.
Class:
Ingress protection IP66. Electric shock protection II w/o ground. IK10.
Light source:
Integrated LED unit: LED 3000K/4000K 8,5W.
Shield/Diffuser: Half shaded opal, Half shaded clear.
PH WALL
Wall lamp
Page: 236
Design: Poul Henningsen
Finish:
Copper, brushed.
Material:
Shades: Spun copper.
Wall box: Copperplated, spun brass.
Arm: Copperplated, brass.
Weight:
Max. 6kg.
Class:
Ingress protection IP23. Electric shock protection I w. ground.
Light source:
100W E27.
TOLDBOD 155 WALL
Wall lamp
Page: 240
Design: Louis Poulsen A/S
Finish:
Aluminium coloured with textured surface or black with textured surface, powder coated.
Material:
Fixture head: Chilled casting aluminium.
Shield: Laser cut acrylic satine.
Wall box: Die cast aluminium.
Arm: Chilled casting aluminium.
Weight:
Max. 1.5kg.
Class:
Ingress protection IP44. Electric shock protection I w. ground. IK05.
Light source:
40W E14.
FLINDT BOLLARD
Bollards
Page: 26 / 244
Design: Christian Flindt
Finish:
Aluminium coloured or corten coloured. Textured surface, powder coated.
Material:
Top: Cast aluminium. Refl ector part: Cast aluminium.
Post: Extruded aluminium. Base plate: Cast aluminium.
Weight:
Max 13kg.
Class:
Ingress protection IP65. Electric shock protection I w. ground,
II w/o ground. IK10.
Light source:
Integrated LED unit: LED 3000K 15W, LED 4000K 15W.
Info notes:
For in-ground installation, with anchorage unite or with baseplate.
TOLDBOD 220/290 WALL
Wall lamp
Page: 240
Design: Louis Poulsen A/S
Finish:
Aluminium coloured with textured surface or black with textured surface, powder coated.
Material:
Fixture head: Die cast aluminium.
Shield: Injection moulded clear polycarbonate.
Wall box: Die cast aluminium.
Arm: Extruded aluminium.
Weight:
Max. 5kg.
Class:
Ingress protection, Ø 220: IP43, IK09. Ø 290: IP44, LED: IP65, IK08. Electric shock protection I w.
ground.
Light source:
Ø 220: 100W E27, Ø 290: LED 3000K 27W.
BYSTED GARDEN
Bollards
Page: 26 / 242
Design: Peter Bysted
Finish:
Aluminium coloured, corten coloured or black, with textured surface, powder coated.
Material:
Top: Cast aluminium. Refl ector part: Cast aluminium. Post: Extruded aluminium. Base plate, spike
and anchor: Cast aluminium. Diffuser: PC
Weight:
Max. 6kg. Preliminary
Class:
Ingress protection w/spike: IP 65. Ingress protection w/anchor: IP 65 (Head), IP44 (Anchor). Ingress
protection w/base plate: IP 65 (Head),
IP44 (Baseplate). Electric shock protection III. IK06
Light source:
LED 2700K, 3000K and 4000K (Alu colour only). No dimming. 17W.
FLINDT GARDEN
Bollards
Page: 26 / 246
Design: Christian Flindt
Finish:
Black, Aluminium coloured, corten coloured or black, with textured surface, powder coated.
Material:
Top: Cast aluminium. Refl ector part: Cast aluminium.
Post: Extruded aluminium. Base plate: Cast aluminium.
Weight:
Max. 5kg.
Class:
Ingress protection w/spike: IP 65. Ingress protection w/anchor: IP 65 (Head), IP44 (Anchor). Ingress
protection w/base plate: IP 65 (Head),
IP44 (Baseplate). Electric shock protection III. IK-Class: IK 5
Light source:
LED 2700K, 3000K and 4000K. No dimming. 10W.
Info notes:
For in-ground installation, with anchorage unite or with baseplate.
NYHAVN WALL
Wall lamp
Page: 232
Design: Alfred Homann
& Ole V. Kjær
Finish:
Copper, brushed or white, wet painted.
Material:
Shades: Spun aluminium or spun copper. Enclosure: Clear glass. Top: Spun aluminium or spun
copper. Wall box: Die cast aluminium. Wall box cover: Spun aluminium or spun copper. Arm: Cop-
perplated, red brass
or steel.
Weight:
Max. 4.5kg.
Class:
Ingress protection IP44. Electric shock protection I w. ground.
Light source:
100W E27.
PH 3-2½ WALL
Wall lamp
Page: 234
Design: Poul Henningsen
Finish:
Black, powder coated.
Material:
Top shade: Spun stainless steel.
Middle/lower shade: Spun stainless steel.
Shadeholder: Form pressed glass.
Wall box: Die cast aluminium.
Wall box cover: Spun aluminium.
Arm: Stainless steel.
Weight:
Max. 2.5kg.
Class:
Ingress protection IP44. Electric shock protection I w. ground.
Light source:
60W E27.
FLINDT WALL 200/300/400
Wall lamp
Page: 26 / 200 / 230
Design: Christian Flindt
Finish:
Aluminum coloured, corten coloured, white or black, with textured surface, powder coated.
Material:
Front and back housing: Die casted. Light engine: Die casted aluminum and
injection molded acrylic.
Weight:
Max. 4.5 kg.
Class:
Ingress protection IP65. Electric shock protection I w. ground. Ø200: IK08. Ø300/400: IK09.
Light source:
Integrated LED unit: Ø200: LED 2700/3000K 10W. Ø300: LED 2700/3000 16W. Ø400: LED
2700/3000 20W.
ALBERTSLUND WALL
Wall lamp
Page: 228
Design: Jens Møller-Jensen
Finish:
Galvanized, grey or white, powder coated.
Material:
Enclosure: Clear glass or partly frosted glass. Saturn ring: Punched aluminium or galvanized,
punched steel. Anti glare ring: Spun aluminium or galvanized, extruded steel. Housing: Die cast
aluminium. Wall box: Die cast aluminium. Arm: Extruded aluminium.
Weight:
Max. 3.5kg.
Class:
Ingress protection IP44. Electric shock protection I w. ground. IK06.
Light source:
100W E27, 18W TC-TEL GX24q-2 HF.
AJ GARDEN
Wall lamp
Page: 24
Design: Arne Jacobsen
Finish:
Outside: Black, textured surface, powder coated. Inside: White, wet paint.
Material:
Head, cast aluminium. Stem and base plate, stainless steel. Spike, cast
aluminium with ABS housing. Anchor: Steel. Diffuser: Injection molded opal PC.
Weight:
Max. 4,3 kg
Class:
Ingress protection: IP 65. Electric shock protection III. IK06
Light source:
LED 4000K 6.5W. Lumen: 524
