DALI2
IP20
SceneCOM EVO | DALI2
62
91
160
DALI2
IP20
DALI2
IP20
NEW
DALI2
IP20
NEW
DALI
IP20
NEW
XC G2 | DALI2
48
15
28
OptiTouch | Display 4” DALI2
30
20
88
OptiTouch | Display 7” DALI2
36
178
28
111
OptiTimer | DALI Real Time Clock
33
15
59
83009
Power supply
83009
Power supply
Type
Signal Output
Input
Connector
83146
WH
3 DALI lines
220-240V AC
CLAMP
Type
Signal Output
Input
Connector
83147
WH
DALI
15-16V DC
CLAMP
Type
Signal Output
Input
Connector
C-E700019
WH
DALI
24V DC
CLAMP
Type
Signal Output
Input
Connector
C-E700020
WH
DALI
24V DC
CLAMP
Type
Signal Output
Input
Connector
C-E700024
WH
DALI
DALI
CLAMP
DALI2 control unit. Maximum number of DALI drivers that can be connected 192. 3 DALI outputs. Web
interface for programming. Schedules and programmable calendar functions
To be used with 83146. 4 independent inputs for contacts and N/O buttons. Possibility of connecting
several XC G2s on the DALI line. Power supply via DALI cable. Connection cables with a length of 25cm
according to the colors of the terminal.
Multifunctional 4” capacitive touch screen for DALI and DALI-2 systems. Addressing and configuration
via user interface, customisable thanks to the many widgets. Tunable RGB and white colour management.
Scenario recall and saving.
Multifunctional 7” capacitive touch screen for DALI and DALI-2 systems. Addressing and configuration via
user interface, customisable thanks to the many widgets. Tunable RGB and white colour management.
Scenario recall and saving. Group configuration. Circadian daylight curves. Weekly programs and sequences.
DALI real-time clock. The time can be set and queried via DALI. Scheduler function - up to 28 items. Easy
programming configuration via DALI Cockpit software and the DALI USB interface. The DALI RTC module
does not need to be connected to the mains. It is powered directly via the DALI signal line. Internal battery,
by default the clock is set to the local time (GMT+1).
