C.C.
IK08
IP20
UGR
NEW
IK08
IP65
NEW
C.C.
IK08
IP20
NEW
Emy | V2 | topLED | 1200 mA | 40 W DC
595
9
Emy | V2 | topLED | 220-240 V AC | 40W AC
595
12
Emy | V2 | topLED | 1200 mA | 40 W DC
1195
9
295
Accessories
Finishes
Cct
Smooth white
W 3000
N
4000
Electronics
Electronics: FN (pag 245) | Accessories (pag 245)
Accessories (pag 245)
Electronics: FN (pag 245) | Accessories (pag 245)
99584
suitable for: Emy C01130 - C01131*
99556
suitable for: Emy 595x595
99898
suitable for: Emy 1195x295
FN
C-E100045 99971.02
ON/OFF
1 art.
100 x 47 x h 27
DALI/PUSH
1 art.
145 x 46 x h 28
55
56
Fin
Cct
lm S - lm D
Opt
CRI 90
C01130
WS
W
4400 - 3569
DI
(Diffused UGR<19)
N
4400 - 4007
Fin
Cct
lm S - lm D
Opt
CRI 90
C01131
WS
W
4400 - 4021
DI
(Diffused)
N
4400 - 4024
Fin
Cct
lm S - lm D
Opt
CRI 90
C01132
WS
N
4400 - On req
DI
(Diffused)
Suspension cables 4 pz.
Surface frame 600x600x50
Surface frame 1200x300x70
*installation over 2.80 meters is recommended.
Not suitable for Emy C01132.
Quick installation
Surface installation on the
modular false ceiling frame
Connection of the Driver
to the electrical mains.
Surface Installation
Frame
accessory
Emy
+
Ceiling / Wall / Suspensions
245
